Klipsch R-2800-CSM Specifications

8" Two-Way In-Ceiling Loudspeaker
With Klipsch's new R-2800-CSM in-ceiling
loudspeaker, affordable architectural audio
has never sounded so good. Upholding the
same high-performance standards as all
Klipsch products, this summed mono model
employs an 8-inch gray polymer woofer
cone and dual 1-inch soft/silk dome
tweeters so that it can play both left and
right stereo signals with total precision and
clarity.
Perfect for use in bathrooms, closets,
hallways or anywhere else multiple speakers
would be impractical, the R-2800-CSM
brings powerful and dynamic performances
to some of the most difficult installation
locations.
In addition to its amazing sound capabilities,
this in-ceiling speaker is one of the most
easy-to-install products on the market. By
utilizing a proprietary two-screw mounting
solution, the R-2800-CSM ensures a secure
fit that saves time and money.
Available in a white finish, this speaker can
be paired with one of Klipsch's new
installation kits (sold separately). Each of
these revolutionary kit designs allow for
increased mounting flexibility and
incorporate a mud ring, wire tie and
universal metal mesh wing for multi-position
placement and a color-coded bracket for
easy speaker size identification.
R-2800-CSM
Single speaker accepts two-channel input
I
Separate tweeters for each channel to maintain stereo effect
I
Weatherized components
I
Time saving two-screw mounting method
I
Paintable to match ceiling
I
S P E C I F I C A T I O N S
FREQUENCY RESPONSE
SENSITIVITY
NOMINAL IMPEDANCE
CROSSOVER FREQUENCY
POWER HANDLING
ENCLOSURE MATERIAL/TYPE
DRIVE COMPONENTS
WIRE GAUGE ACCOMMODATED
WEIGHT
DIAMETER
MOUNTING DEPTH
CUTOUT DIMENSIONS
FINISH
INSTALLATION KIT
All specifications are subject to change without notice. ©2004
52Hz-20kHz ± 3dB
94dB @ 1 watt/1 meter
8 ohms
3400Hz
50 watts (200 watts peak)
ABS/ Infinite baffle, front flush with ceiling
Two-way system using dual 1" (2.54cm) silk
dome tweeters and one 8" (20.3cm)
polymer woofer
12
7.9 lbs. (3.6kg)
11" (27.94cm)
4.5" (11.43cm)
9.75" (24.77cm)
White
IK-800-C (sold separately)
www.klipsch.com
1-800-KLIPSCH
