Klipsch R-2502-W Specification Sheet

In-Wall Loudspeaker
The R-2502-W employs dual 5.25-inch
polymer woofer cones for accurate sound
with dynamic detail, while a silk dome
tweeter mated to a symmetrical pattern
90 x 90 conical horn generates flat in-room
frequency response with high efficiency and
low distortion. The speaker's precision-
voiced crossover networks further ensure
that the high and low frequencies are
faithfully reproduced.
This in-wall speaker also consistently
delivers thrilling, realistic sound, whether
it's installed horizontally or vertically. It fea-
tures all-new sure-grip mounting dogs that
provide even pressure against drywall for
long-term installation reliability, and includes
a paintable grille that blends in perfectly with
any décor. IR receiver knockout holes allow
for infrared repeaters, bringing custom
configuration to installers.
Furthermore, the R-2502-W offers unlimited
flexibility. It is timbre matched to all of our
2000 series architectural products, so you
can mix and match to create an affordable,
discreet stereo or home theater system
that's just right for you.
R-2502-W
• Perfect for left, center or right channel use
• Easily mounts horizontally or vertically
• Horn-loaded for high efficiency and low distortion
• IR receiver knockouts
• Maximum installation reliability
• Mix and match with our 2000 series products
S p e c i f i c a t i o n S
frequency response
power handling
recommended amplifier power
sensitivity
nominal impedance
high frequency drivers
high freq crossover
low frequency drivers
enclosure material
enclosure type
dimensions
mounting depth
cutout dimensions
installation kit
weight
finishes
All specifications are subject to change without notice. ©2008
47Hz-20kHz +/-3dB
60W continuous / 240W peak
110W
91dB @ 2.83V / 1m
8 ohms compatible
1" (2.5cm) Silk dome tweeter
2200Hz
Dual 5.25" (13.3cm) polypropylene
cone woofers
ABS
Infinite baffle, front flush with wall
17.75" (45.1cm) H x
8" (20.3cm) W
3.5" (8.9cm)
16.5" (41.9cm) H x 6.5"
(16.5cm) W
IK-502-W (sold seperately)
6.25lbs (2.8kg)
White paintable frame and grille
www.klipsch.com
1-800-KLIPSCH
