Klipsch R-2650-W Specifications

6.5" Two-Way In-Wall Loudspeaker
The affordable R-2650-W
loudspeaker makes discrete audio a
convincing reality for almost anyone. Built to
the same exacting standards as all Klipsch
products, this high-performance model
doesn't suffer from the design shortcuts and
sonic compromises that plague competing
designs.
This exceptional speaker employs a 6.5-inch
gray polymer woofer cone and 1-inch
soft/silk dome tweeter to deliver mind-
bending depth and clarity.
Available in a white finish, the R-2650-W can
be paired with one of Klipsch's new
installation kits (sold separately). Each of
these revolutionary kit designs allow for
increased mounting flexibility and
incorporate a mud ring, wire tie and
universal metal mesh wing for multi-position
placement and a color-coded bracket for
easy speaker size identification.
R-2650-W
Good sensitivity and power handling
in-wall
I
Single piece grille frame and rustproof aluminum grille
I
IR receiver knock out
I
Weatherized components
I
S P E C I F I C A T I O N S
FREQUENCY RESPONSE
SENSITIVITY
NOMINAL IMPEDANCE
CROSSOVER FREQUENCY
POWER HANDLING
ENCLOSURE MATERIAL/TYPE
DRIVE COMPONENTS
WIRE GAUGE ACCOMMODATED
WEIGHT
HEIGHT
WIDTH
MOUNTING DEPTH
CUTOUT DIMENSIONS
FINISH
INSTALLATION KIT
All specifications are subject to change without notice. ©2004
65Hz-20kHz ± 3dB
91dB @ 1 watt/1 meter
8 ohms
1800Hz
50 watts (200 watts peak)
ABS/ Infinite baffle, front flush with wall
Two-way system using one 1" (2.54cm)
silk dome tweeter and one 6.5" (16.51cm)
polymer woofer
12
7.2 lbs. (3.25kg)
14.3" (36.32cm)
9.3" (23.62cm)
3.75" (9.5cm)
13" (33.02cm) x 8" (20.32cm)
White
IK-650-W (sold separately)
www.klipsch.com
1-800-KLIPSCH
