Klipsch R-2650-CSM Specifications

6.5" Two-Way In-Ceiling Loudspeaker
Easy to integrate into almost any lifestyle,
the R-2650-CSM summed mono speaker
brings powerful and dynamic Klipsch sound
to challenging home installation locations
such as hallways, bathrooms, closets and
areas that can't accommodate multiple
speakers.
Upholding the same high-performance
standards as all Klipsch products, this
reasonably priced speaker employs a 6.5-
inch gray polymer woofer cone and dual 1-
inch soft/silk dome tweeters so that it can
play both left and right stereo signals with
total precision and clarity.
Because it nicely blends in with its
surroundings and offers installation flexibility,
this amazing performer is sure to be a
homeowner and residential contractor
favorite. By incorporating a proprietary two-
screw mounting solution, all it takes is one
trip up the ladder to get this speaker rockin'.
Available in a white finish, the R-2650-CSM
can be paired with one of Klipsch's new
installation kits (sold separately). Each of
these revolutionary kit designs allow for
increased mounting flexibility and
incorporate a mud ring, wire tie and
universal metal mesh wing for multi-position
placement and a color-coded bracket for
easy speaker size identification.
R-2650-CSM
Single speaker accepts two-channel input
I
Separate tweeters for each channel to maintain stereo effect
I
Weatherized components
I
Time saving two-screw mounting method
I
Paintable to match ceiling
I
S P E C I F I C A T I O N S
FREQUENCY RESPONSE
SENSITIVITY
NOMINAL IMPEDANCE
CROSSOVER FREQUENCY
POWER HANDLING
ENCLOSURE MATERIAL/TYPE
DRIVE COMPONENTS
WIRE GAUGE ACCOMMODATED
WEIGHT
DIAMETER
MOUNTING DEPTH
CUTOUT DIMENSIONS
FINISH
INSTALLATION KIT
All specifications are subject to change without notice. ©2004
75Hz-20kHz ± 3dB
92dB @ 1 watt/1 meter
8 ohms
3000Hz
50 watts (200 watts peak)
ABS/ Infinite baffle, front flush with ceiling
Two-way system using dual 1" (2.54cm) silk
dome tweeters and one 6.5" (16.51cm)
polymer woofer
12
7.2 lbs. (3.25kg)
9.5" (24.13cm)
4.2" (10.67cm)
8.25" (21cm)
White
IK-650-C (sold separately)
www.klipsch.com
1-800-KLIPSCH
