Klipsch R-2650-C Specifications

6.5" Two-Way In-Ceiling Loudspeaker
By upholding the same best-in-class
standards as all Klipsch products, the R-
2650-C in-ceiling loudspeaker makes it
possible to bring high-performance audio
into the home without taking up valuable
floor space.
This no-comprise, yet affordable, speaker
employs a 6.5-inch gray polymer woofer
cone and a 1-inch soft/silk dome tweeter to
deliver mind-bending depth and clarity. By
incorporating a proprietary two-screw
mounting solution, the R-2650-C is also
one of the most easy-to- install products on
the market.
Available in a white finish, this speaker can
be paired with one of Klipsch's new
installation kits (sold separately). Each of
these revolutionary kit designs allow for
increased mounting flexibility and
incorporate a mud ring, wire tie and
universal metal mesh wing for multi-position
placement and a color-coded bracket for
easy speaker size identification.
R-2650-C
Good sensitivity and power handling
I
Weatherized components
I
Rugged ABS frame
I
Time saving two-screw mounting method
I
Paintable to match ceiling
I
S P E C I F I C A T I O N S
FREQUENCY RESPONSE
SENSITIVITY
NOMINAL IMPEDANCE
CROSSOVER FREQUENCY
POWER HANDLING
ENCLOSURE/MATERIAL TYPE
DRIVE COMPONENTS
WIRE GAUGE ACCOMMODATED
WEIGHT
DIAMETER
MOUNTING DEPTH
CUT OUT DIMENSIONS
FINISH
INSTALLATION KIT
All specifications are subject to change without notice. ©2004
77Hz-20kHz ± 3dB
91dB @ 1 watt/1 meter
8 ohms
2700Hz
50 watts (200 watts peak)
ABS/Infinite Baffle, front flush
Two-way system using one 1"(2.54cm)
silk dome tweeter and one 6.5" (16.51cm)
polymer woofer
12
7.2 lbs. (3.25kg)
9.55" (24.13cm)
4.2" (10.67cm)
8.25" (21cm)
White
IK-650-C (sold separately)
www.klipsch.com
1-800-KLIPSCH
