SC22225
welcoming • sophisticated • inspiring
WALL SCONCE
1
RATED FOR
DAMP
LOCATIONS
ITEM #4968595
MODEL #42620
Español p. 13

Advertisement

loading
Need help?

Need help?

Do you have a question about the 42620 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Allen + Roth 42620

  • Page 1 • sophisticated • inspiring RATED FOR DAMP LOCATIONS ITEM #4968595 ALLEN + ROTH and logo design are trademarks WALL SCONCE or registered trademarks of LF, LLC. All rights reserved. MODEL #42620 ATTACH YOUR RECEIPT HERE Español p. 13 Purchase Date _________________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 866-439-9800, 8 a.m.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Package Contents..............3 Hardware Contents.
  • Page 3: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY Fixture Shade Screw Cap Switch (preassembled to Fixture [A]) Wall Plate (preassembled to Fixture [A]) Mounting Screws (preassembled to Wall Plate [E]) Power Cord (preassembled to Fixture [A]) Plug (preassembled to Power Cord [G]) Hex Nut (preassembled to Mounting Screws [F] Grommet (preassembled to Fixture [A]) Socket Ring (preassembled to Fixture [A]) Tube...
  • Page 4: Safety Information

    SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. Failure to do so could lead to electrical shock, fire or other injuries that could be hazardous or even fatal. • Before you begin installing the light fixture, disconnect the power by removing fuses or turning off the circuit breakers.
  • Page 5: Assembly Instructions For Plug-In Installation

    ASSEMBLY INSTRUCTIONS FOR PLUG-IN INSTALLATION 1. Turn off the circuit breakers and the wall switch to the supply line leads. DANGER: Failure to disconnect the power supply prior to installation may result in serious injury or death. 2. This fixture has two options for installation. To install the fixture using the plug-in method, continue to the next step.
  • Page 6 ASSEMBLY INSTRUCTIONS FOR PLUG-IN INSTALLATION 4. Align the keyhole slots on the wall plate (E) with the screws (AH) on the wall and then gently push the wall plate (E) against the wall and slide down until secure. 5. Insert tube (L) into the threaded hole in the bottom of fixture (A) and twist in a clockwise direction until secure.
  • Page 7 ASSEMBLY INSTRUCTIONS FOR PLUG-IN INSTALLATION 7. Install candelabra-base (E12) bulb (sold separately) in socket of fixture (A). Bulb (sold Important: Make sure you allow the bulbs and fixture separately) (A) to cool before you replace the bulb. Assembly is complete. Turn ON the electrical power at the main fuse or circuit breaker.
  • Page 8: Assembly Instructions For Hardwire Installation

    ASSEMBLY INSTRUCTIONS FOR HARDWIRE INSTALLATION 1. Turn off the circuit breakers and the wall switch to the supply line leads. DANGER: Failure to disconnect the power supply prior to installation may result in serious injury or death. 2. This fixture has two options for installation. To install the fixture using the hardwire method, continue to the next step.
  • Page 9 ASSEMBLY INSTRUCTIONS FOR HARDWIRE INSTALLATION 4. Use the two mounting bracket screws (RR) to attach the mounting bracket (FF) to the outlet box (sold separately). Note: Ensure the mounting bracket screws (RR) are parallel to the horizon. Hardware Used Mounting Bracket Mounting Outlet...
  • Page 10 ASSEMBLY INSTRUCTIONS FOR HARDWIRE INSTALLATION 7. Remove the hex nut preassembled to plug button (EE). Then insert the plug button (EE) through grommet (J) and secure with the hex nut. Hardware Used Plug Button Hex Nut 8. Make the following wire connections using the wire connectors preassembled to the fixture (A) wires: Bare/Green •...
  • Page 11 ASSEMBLY INSTRUCTIONS FOR HARDWIRE INSTALLATION 10. Turn socket ring (K) counterclockwise to remove from the socket of fixture (A). Place shade (B) over socket and secure with socket ring (K) by turning in a clockwise direction. 11. Install candelabra-base (E12) bulb (sold separately) in socket of fixture (A).
  • Page 12: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Bulb will not light. 1. Fixture may be wired 1. Check wiring. incorrectly. 2. Replace bulb. 2. Worn or broken bulb. 3. Ensure switch is in ON position. ONE-YEAR LIMITED WARRANTY The manufacturer warrants all of its lighting fixtures against defects in materials and workmanship for one (1) years from the date of purchase.
