MODEL W1667
8-1/2" OSCILLATING
DRILL PRESS
OWNER'S MANUAL
(FOR MODELS MANUFACTURED SINCE 06/22)
Phone: (360) 734-3482 • Online Technical Support: techsupport@woodstockint.com
COPYRIGHT © 2000 BY WOODSTOCK INTERNATIONAL, INC., REVISED SEPTEMBER, 2022 (CS)
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT
THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC.
***Keep for Future Reference***
V3.09.22
#4884CR Printed in China

Advertisement

Table of Contents
loading

Related Manuals for Woodstock SHOP FOX W1667

Summary of Contents for Woodstock SHOP FOX W1667

  • Page 1 (FOR MODELS MANUFACTURED SINCE 06/22) Phone: (360) 734-3482 • Online Technical Support: techsupport@woodstockint.com COPYRIGHT © 2000 BY WOODSTOCK INTERNATIONAL, INC., REVISED SEPTEMBER, 2022 (CS) WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC.
  • Page 2 This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.

  • Page 3: Table Of Contents

    Contents INTRODUCTION........2 ACCESSORIES........31 Woodstock Technical Support ....2 Drill Press Accessories ......31 Controls & Components ......6 MAINTENANCE........32 SAFETY..........8 General .......... 32 Standard Machinery Safety Instructions ..8 Cleaning & Protecting ......32 Additional Safety for Drill Presses ... 10 Sanding Sleeves .........

  • Page 4: Introduction

    Woodstock International, Inc. is committed to customer satisfaction. Our intent with this manual is to include the basic information for safety, setup, operation, maintenance, and service of this product.
  • Page 5 Model W1667 (For Machines Mfd. Since 06/22) MODEL W1667 8­1/2" OSCILLATING DRILL PRESS Product Dimensions Weight......................49 lbs. Width (side‐to‐side) x Depth (front‐to‐back) x Height.......... 9 x 17 x 23 in. Footprint (Length x Width)..............12‐1/4 x 7‐3/4 in. Shipping Dimensions Type....................
  • Page 6 Model W1667 (For Machines Mfd. Since 06/22) Main Specifications Operation Information Type....................Oscillating Swing....................8‐1/2 in. Spindle Taper..................... JT‐33 Spindle Travel....................2 in. Max. Distance From Spindle to Column............4‐5/16 in. Max. Distance From Spindle to Table..............8 in. Number of Spindle Speeds................... 5 Range of Spindle Speeds..............
  • Page 7 Model W1667 (For Machines Mfd. Since 06/22) Identification Become familiar with the names and locations of the controls and features shown below to better understand the instructions in this manual. Belt Cover Belt Tension Knob Chuck Guard Motor ON/OFF Switch w/Disabling Key Depth Stop Spindle Handle...

  • Page 8: Controls & Components

    Model W1667 (For Machines Mfd. Since 06/22) Controls.&.Components Refer to the Figures.1–4 and the following descriptions to become familiar with the basic controls and components of this machine. Understanding these items and how they work will help you understand the rest of the manual and stay safe when operating this machine.
  • Page 9 Model W1667 (For Machines Mfd. Since 06/22) F.. Oscillation.Belt.&.Pulley:.Oscillates spindle for sanding operations. G.. Motor.Pulley:.Transfers motor power to drive belt at different speeds. H.. Drive.Belt:.Controls spindle speed. I.. Spindle.Pulley:.Holds drive belt and transfers motor power to spindle. Figure.3. Inside belt cover. J..

  • Page 10: Safety

    Model W1667 (For Machines Mfd. Since 06/22) SAFETY SAFETY For.Your.Own.Safety, Read.Manual.Before.Operating.Machine The. purpose. of. safety. symbols. is. to. attract. your. attention. to. possible. hazardous. conditions.. This. manual.uses.a.series.of.symbols.and.signal.words.intended.to.convey.the.level.of.importance.of.the. safety.messages..The.progression.of.symbols.is.described.below..Remember.that.safety.messages.by. themselves. do. not. eliminate. danger. and. are. not. a. substitute. for. proper. accident. prevention. mea- sures—this.responsibility.is.ultimately.up.to.the.operator! Indicates.an.imminently.hazardous.situation.which,.if.not.avoided,.
  • Page 11 INTENDED.USAGE..Only use machine for its keep machine in good working condition. A intended purpose—never make modifications machine that is improperly maintained could without prior approval from Woodstock malfunction, leading to serious personal injury International. Modifying machine or using or death.

  • Page 12: Additional Safety For Drill Presses

    Model W1667 (For Machines Mfd. Since 06/22) Additional.Safety.for.Drill.Presses Serious injury or death can occur from getting clothing, jewelry, or long hair entangled in rotating spindle or bit/cutting tool. Contact with rotating bit/cutting tool can result in severe cuts or ampu- tation of fingers.

  • Page 13: Electrical

    Model W1667 (For Machines Mfd. Since 06/22) ELECTRICAL Circuit.Requirements This machine must be connected to the correct size and type of power supply circuit, or fire or electrical damage may occur. Read through this section to determine if an The machine must be properly set up adequate power supply circuit is available.

  • Page 14: Grounding Requirements

    Model W1667 (For Machines Mfd. Since 06/22) Grounding.Requirements This machine MUST be grounded. In the event of certain types of malfunctions or breakdowns, grounding provides GROUNDED 110V 5-15 RECEPTACLE a path of least resistance for electric current to travel—in order to reduce the risk of electric shock. Grounding Pin Improper connection of the equipment-grounding wire will increase the risk of electric shock.

  • Page 15: Setup

    Model W1667 (For Machines Mfd. Since 06/22) SETUP Unpacking This machine has been carefully packaged for safe transportation. If you notice the machine has been damaged during shipping, please contact your authorized This machine presents Shop Fox dealer immediately. serious injury hazards to untrained users.

  • Page 16: Inventory

    Model W1667 (For Machines Mfd. Since 06/22) Inventory The following is a list of items shipped with your machine. Before beginning setup, lay these items out and inventory them. Note: If you cannot find an item on this list, carefully check around/inside the machine and packaging materials.

  • Page 17: Machine Placement

    Model W1667 (For Machines Mfd. Since 06/22) Machine.Placement Cleaning.Machine Workbench.Load The unpainted surfaces of your machine are coated with a heavy-duty rust preventative that Refer to the Machine.Specifications for the prevents corrosion during shipment and storage. weight and footprint specifications of your This rust preventative works extremely well, but machine.

  • Page 18: Bench Mounting

    Model W1667 (For Machines Mfd. Since 06/22) Bench.Mounting Number.of.Mounting.Holes........5 Diameter.of.Mounting.Hardware.Needed....⁄ " Bolt The base of this machine has mounting holes that allow it to be fastened to a workbench or other mounting surface to prevent it from moving during operation and causing Flat Washer accidental injury or damage.

  • Page 19: Assembly

    Model W1667 (For Machines Mfd. Since 06/22) Assembly Before beginning the assembly process, refer to Items. Needed.for.Setup and gather everything you need. Column Ensure all parts have been properly cleaned of any heavy-duty rust-preventative applied at the factory (if applicable). Be sure to complete all steps in the assembly procedure prior to performing the Test.Run.or connecting the machine to power.
  • Page 20 Model W1667 (For Machines Mfd. Since 06/22) 6.. Place table on column, then secure with table lock handle (see Figure 13). Figure.13. Table installed on column. 7.. With lifting assistant, place headstock on column and allow headstock to slide down until column fully seats in headstock (see Figure 14).
  • Page 21 Model W1667 (For Machines Mfd. Since 06/22) 12.. Thread (3) spindle handles into hub, as shown in Figure 16. Spindle Handle (1 of 3) Figure.16. Example of installing spindle handles. 13.. Attach chuck guard to chuck guard seat with (3) M2.2 x 4.5 tap screws (see Figure 17).

  • Page 22: Dust Collection

    Model W1667 (For Machines Mfd. Since 06/22) Dust.Collection Recommended.CFM.at.Dust.Port:....100.CFM Do not confuse this CFM recommendation with the rating of the dust collector. To determine the CFM at the dust port, you must consider these variables: (1) CFM rating of the dust collector, (2) hose type and length between the dust collector and the machine, (3) number of branches or wyes, and (4) amount of other open lines throughout...

  • Page 23: Test Run

    Model W1667 (For Machines Mfd. Since 06/22) Test.Run Once assembly is complete, test run the machine to ensure it is properly connected to power and safety components are functioning properly. Serious. injury. or. death. can. result. from. using. this. machine. BEFORE. If you find an unusual problem during the test run, understanding.

  • Page 24: Operations

    Model W1667 (For Machines Mfd. Since 06/22) OPERATIONS General This machine will perform many types of operations that are beyond the scope of this manual. Many of these operations can be dangerous or deadly if performed incorrectly. The instructions in this section are written with the understanding that the operator has the necessary knowledge and skills to operate this machine.

  • Page 25: Adjusting Table

    Model W1667 (For Machines Mfd. Since 06/22) Adjusting.Table You can adjust the table height and tilt to accommodate the workpiece height or achieve special drilling/sanding Table Lock angles. You can also move the table out of the way and Handle use the drill press base as a table for drilling/sanding.

  • Page 26: Changing Spindle Speed

    Model W1667 (For Machines Mfd. Since 06/22) Changing.Spindle.Speed The Model W1667 has 5 speeds, ranging from 620 to 3100 RPM. Refer to the speed charts location under the belt cover while following the instructions below. To.change.spindle.speed,.do.these.steps: 1. DISCONNECT MACHINE FROM POWER! 2.
  • Page 27 Model W1667 (For Machines Mfd. Since 06/22) ... . & ....http://www.woodstockint.com. -25-...

  • Page 28: Drill Press Speed Chart

    Model W1667 (For Machines Mfd. Since 06/22) Drill.Press.Speed.Chart Use Figure 26 to select the optimum motor-to-spindle pulley ratio for your operations. Figure.26. Drill press RPM chart. -26-...

  • Page 29: Changing Drill Bit/Drum

    Model W1667 (For Machines Mfd. Since 06/22) Changing.Drill.Bit/Drum Any drill bit or sanding drum you install in the chuck must be tight enough that it will not come loose during operation. To.change.drill.bit.or.drum,.do.these.steps: 1. DISCONNECT MACHINE FROM POWER! 2. Use chuck key to open chuck wide enough to remove installed bit or drum, then open it enough to accept new bit or sanding drum mandrel (see Figure 27).

  • Page 30: Adjusting Depth Stop

    Model W1667 (For Machines Mfd. Since 06/22) Adjusting.Depth.Stop Your new drill press is fitted with a depth stop that allows drilling holes at a preset depth. BACK. OFF. depth. stop. completely. and. Tools.Needed. secure.stop.nuts.before.using.oscillating. Open-End Wrenches 17mm ........2 feature.. If. depth. stop. is. left. adjusted. Scrap Stock ..........

  • Page 31: Using Oscillator

    Model W1667 (For Machines Mfd. Since 06/22) Using.Oscillator One of the great features of the Model W1667 Oscillating Drill Press is its sanding capability. The drill press can be converted from drilling operations to sanding operations in Remove.all.three.spindle.handles.before. just a few steps. using.
  • Page 32 Model W1667 (For Machines Mfd. Since 06/22) 7. Refer to Changing Drill Bit/Drum on Page 27 to install desired sanding drum and table insert. — For general drill bits, small reamers, and miscellaneous small cutting and sanding bits, use ⁄ '' and the 1'' table inserts.

  • Page 33: Accessories

    Inc. Dealer. If you do not have a dealer in your area, these products are also available through online dealers. Please call or e-mail Woodstock International Inc. Customer Service to get a current listing of dealers at: 1-800-840-8420 or at sales@woodstockint.com.

  • Page 34: Maintenance

    Model W1667 (For Machines Mfd. Since 06/22) MAINTENANCE General For optimum performance from this machine, this maintenance schedule must be strictly followed. Ongoing To minimize your risk of injury and maintain proper machine operation, shut down the machine immediately if you ever observe any of the items below, and fix the problem before continuing operations: •...

  • Page 35: Inspecting/Replacing Belts

    Model W1667 (For Machines Mfd. Since 06/22) Inspecting/Replacing. Belts Inspect the belts regularly for tension and wear. The oscil- lator belt tension is not adjustable. If the oscillator belt shows cracks or is slipping on the pulleys, replace the belt with a new one.
  • Page 36 Model W1667 (For Machines Mfd. Since 06/22) Quill.&.Column.Surfaces Lubrication Type ....... ISO 68 Way Oil Lubrication Amount ........Thin Coat Lubrication Frequency ....8 Hrs. of Operation Move the spindle all the way down to access the smooth surfaces of the quill (see Figure 38). Adjust table height as necessary to access entire length of column (see Figure 39).

  • Page 37: Service

    If you require additional machine service not included in this section, please contact Woodstock International Technical Support at (360) 734-3482 or send e-mail to: techsupport@woodstockint.com. Adjusting.Quill.Shaft.

  • Page 38: Tensioning Feed Shaft Return Spring

    Model W1667 (For Machines Mfd. Since 06/22) Tensioning.Feed.Shaft. Return.Spring The feed shaft return spring is adjusted at the factory; however, during the life of the drill press you may want to adjust the feed shaft return spring at a stronger return return spring pressure.
  • Page 39 Model W1667 (For Machines Mfd. Since 06/22) 4. Put on thick leather gloves and hold spring cover Locking against side of headstock so cover stays splined with locking lug, remove jam nut, then loosen cover nut " (6.4mm) (see Figure 45). approximately ⁄...

  • Page 40: Troubleshooting

    Model W1667 (For Machines Mfd. Since 06/22) Troubleshooting The following troubleshooting tables cover common problems that may occur with this machine. If you need replacement parts or additional troubleshooting help, contact our Technical Support. Note: Before contacting Tech Support, find the machine serial number and manufacture date, and if available, your original purchase receipt.
  • Page 41 Model W1667 (For Machines Mfd. Since 06/22) Operation PROBLEM POSSIBLE.CAUSE CORRECTIVE.ACTION Tool falls out or 1. Chuck jaws loose. 1. Tighten chuck jaws. loose in chuck. 2. Debris on tool. 2. Clean tool, then re-install. 3. Excessive feed pressure. 3. Decrease feed pressure and allow chips to clear. 1.

  • Page 42: Electrical Safety Instructions

    Model W1667 (For Machines Mfd. Since 06/22) Electrical.Safety.Instructions These pages are current at the time of printing. However, in the spirit of improvement, we may make changes to the electrical systems of future machines. Compare the manufacture date of your machine to the one stated in this manual, and study this section carefully.

  • Page 43: Wiring Diagram

    Model W1667 (For Machines Mfd. Since 06/22) Wiring.Diagram Belt Cover Limit Switch KEDU HY69-8 ON/OFF Switch KEDU HY18 Ground Figure.48. ON/OFF and limit switch wiring. Neutral Read Ground Page 40 STOP 110 VAC Before Wiring 5-15 Plug Ground Run Capacitor CBB60 24uF 300V Figure.47.

  • Page 44: Parts

    Model W1667 (For Machines Mfd. Since 06/22) PARTS Main 33-4 33-5 33-6 33-1 33-3 33-2 15-1 13 14 104-3 104-1 104-2 104-5 104-4 -42-...
  • Page 45 Model W1667 (For Machines Mfd. Since 06/22) Main.Parts.List REF PART # DESCRIPTION PART # DESCRIPTION X1667001 BASE X1667045 INT RETAINING RING 40MM X1667002 COLUMN X1667046 BALL BEARING 6203-2RS X1667003 HEX BOLT M8-1.25 X 20 X1667047 QUILL ASSEMBLY X1667004 TABLE BRACKET X1667048 RETAINING RING X1667005...

  • Page 46: Labels & Cosmetics

    4. Disconnect power before setting up or servicing. gloves to prevent getting Weight: 49 lbs. Mfd. for Woodstock in China 5. Tie back long hair, roll up long sleeves, and DO NOT wear loose clothing, gloves, or jewelry. during operation.

  • Page 47: Warranty

    Woodstock International, Inc. will repair, replace, or arrange for a dealer refund, at its expense and option, the Shop Fox machine or machine part proven to be defective for its designed and intended...
  • Page 48 High Quality Machines and Tools Woodstock International, Inc. carries thousands of products designed to meet the needs of today’s woodworkers and metalworkers. Ask your dealer about these fine products: ® WHOLESALE ONLY Phone: (360) 734-3482 Fax: (360) 671-3053 Toll Free Fax: (800) 647-8801 P.O.
