1/12 UDISPORT 4X4 OFFROAD TRUCK
OPERATING
INSTRUCTIONS
FULL PROPORTIONAL REMOTE CONTROL UDIRACING SERIES
Our company's products are improving all the time,design and specifications are subject to
Important
change without notice. All the information in this manual has been carefully checked to ensure
Notice
accuracy, if any printing errors, our company reserve the final interpretation right.
UD1201 / UD1202
This product is suitable for users over 14 years old.
Please read this instruction manual carefully befores use.
V1.0
Advertisement
Related Manuals for udir/c UD1201
Summary of Contents for udir/c UD1201
- Page 1 UD1201 / UD1202 1/12 UDISPORT 4X4 OFFROAD TRUCK OPERATING INSTRUCTIONS FULL PROPORTIONAL REMOTE CONTROL UDIRACING SERIES V1.0 This product is suitable for users over 14 years old. Please read this instruction manual carefully befores use. Our company's products are improving all the time,design and specifications are subject to Important change without notice.
- Page 2 THANK YOU ● Thank you for choosing this product. The remote control model is designed to be fun to drive and uses high quality parts to improve durability and performance. The instruction manual you are reading is to make the product easier to understand and explain more thoroughly.
- Page 3 WARNING Before Operation ● Read the instruction manual in detail, or ask for the person with experience in operation, and read with the guardian if necessary. ● Make sure all screws and nuts are properly tightened. ● The remote control and the vehicle should always use the battery with saturated power to avoid losing control of the model.
-
Page 4: Product Maintenance
Product maintenance When not in use, remove Please remove the sediment the battery from the and dirt on the car model and transmitter. completely and must be kept dry after play. Apply lubricating Please separate oil to external the car and battery metal parts. - Page 5 Model Car Summary P12-001 P12-024 P12-040 P12-002 P12-025 P12-040...
- Page 6 P12-008 P12-020 P12-006 P12-019 P12-023 P12-005 P12-012 P12-017 P12-013 P12-006 P12-026 P12-034 P12-043 P12-009 P12-022 P12-011 P12-007 P12-029 P12-042 M02-003 P12-036 P12-003 P12-035...
-
Page 7: Electronic Speed Controller
Electronic speed controller Top lights jack jack Heating plate Front &Rear lights jack Power input Motor Antenna Power switch Jack CH4 expansion jack Fan expansion jack Steering gear jack CH2 expansion jack Preparation of transmitter Transmitter function main interface CH1, Steering wheel Turn left / Turn right Power switch CH2, Throttle trigger... - Page 8 Electronic stability system (ESP) gyroscope Steering range Steering trim knob action ratio adjusting knob adjustment knob High Throttle reverse Steering reverse Turn left Backward Turn right Forward Forward Turn right Backward Turn left Car status indicator (green) Transmitter indicator (red) When the battery of cars is in low battery, the indicator When the signal is weak or interrupted, the indicator will light will flash.
- Page 9 Adjustment of gyroscope action ratio This product has the function of ESP car stability system, which can effectively correct the car attitude and direction when the car skids or loses control. The function and sensitivity of the car gyroscope sensor can be adjusted through the ESP knob of the transmitter. The action ratio The action ratio decreased...
- Page 10 Battery charging The battery contains less power when leaving the factory, Connect the attached charger with the model battery charging so it must be charged and saturated before use. input port, and then connect other USB output ports. When charging, the charging indicator is flashing, and the indicator is always on after charging.
-
Page 11: Operational Guidance
Operational guidance Frequency matching 1> Turn on the power of the transmitter, and the red indicator light Do not touch the will flash quickly. throttle trigger when turning on thepower of the transmitter. Press for 2 second to turn on the power. The lights Consistent direction flash and enter the frequency matching state. - Page 12 Steering wheel Steering wheel Turn left Turn right Turn left and move forward Turn right and move forward Throttle trigger Steering wheel Throttle trigger Steering wheel Go forward Turn left Go forward Turn right Turn left and move backward Turn right and move backward Throttle trigger Steering wheel Throttle trigger...
-
Page 13: Parts Exploded View
Parts exploded view Installation of wheels Use the hexagon nut wrench to take out the nut fixing the tire(M02-003) and remove the old tires. Put on new tires. Hexagon nut wrench M06-010 P12-035 P12-003 M02-003... - Page 14 Assembly of front suspension arm M01-013 P12-007 P12-042 P12-009 P12-036 M03-007 P12-007 M03-007 M01-013 Assembly of rear suspension arm P12-008 M01-035 P12-037 M03-007 M03-007 P12-009 P12-008 M01-035...
- Page 15 Assembly of steering servo M01-032 M01-032 P12-017 M01-032 P12-014 M03-007 P12-018 M01-019 M01-017 P12-010 M05-035 M05-032 M01-022 M03-007 P12-018 M01-033 P12-010 M05-035 M01-033 P12-010 M05-035 M03-007 M03-007...
- Page 16 Assembly of front(rear) differentials P12-030 Assembly of front bumper M01-016 M01-003 P12-022 M01-003 P12-011 P12-011 M01-013...
- Page 17 Assembly of rear bumper M01-034 P12-012 P12-023 M01-003 M01-016 M01-003 M01-003 P12-013 P12-013 M01-034 M01-003 P12-012 M01-013 Assembly of motor M01-004 P12-020 P12-015 M01-010 P12-038 P12-021 M01-030...
- Page 18 Front and rear shock absorbers P12-029 Assembly of chassis M01-012 P12-031 P12-005 P12-005...
- Page 19 Installation of Bracket and Bulkhead tie bars P12-006 P12-005 P12-032 M01-004 M01-012 P12-033 P12-007 P12-007 M01-036 M06-011...
- Page 20 Buyable accessories P12-001A P12-001B P12-002A P12-002B Body assembly Body assembly Body assembly Body assembly P12-003 P12-004 P12-005 P12-006 Wheel × 4 Wheel × 4 Chassis Front & Rear shock tower assembly P12-007 P12-008 P12-009 P12-010 Suspension arms (front) Suspension arms (rear) Front &...
- Page 21 P12-019 P12-020 P12-021 P12-022 Electronic speed controller Motor assembly Motor gear Headlight group (ESC) P12-023 P12-024 P12-025 P12-026 Taillight group 1201 Domelight group 1202 Domelight group Model battery P12-027 P12-028 P12-029 P12-030 Charger Transmitter Front & Rear Differential assembly shock absorber × 2 P12-031 P12-032 P12-033...
- Page 22 P12-039 P12-040 P12-041 P12-042 Main spur gear Body clips × 4 Main driveshaft Front wheel seat cover ø6.25×216mm P12-043 Bind Velcro M01-003 M01-004 M01-008 M01-010 Hexagon socket head cap Hexagon socket head cap Hexagon socket head cap Hexagon socket head cap Hexagon socket head cap tapping screw tapping screw...
- Page 23 M01-030 M01-032 M01-033 M01-034 Hexagon socket button head Hexagon socket button head Hexagon socket button head Set screw tapping screw machine screw shoulder machine screw ø3×4mm ø2.6×12mm TB ø2.5×18mm TM ø3.5×14+3×6mm M01-035 M01-036 Hexagon socket button head Hexagon socket button head half threaded tapping screw half threaded tapping screw ø3.5×29mm...
- Page 24 FCC Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interferencein a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
