UCX24-E009
Data
参数
Rated voltage (V)
No load current (A/7.4V)
No-load speed (rpm/7.4V)
Internal resistance of motor (m )(environment temperature 25 °C)
电机内阻(mΩ)(环境温度:25℃)
Total weight(g)
Whole machine withstand voltage (DC)
Balance quality of rotor (mg)
0perating environment temperature (°C)
Storage temperature (°C)
Storage humidity (%)
Overall height (mm)
Motor height (mm)
Outer diameter of the whole machine (mm)
Installation hole position (mm)
Wire and wire sequence
线材、线序
Length of outgoing line (mm)
出线长度(mm)
电机指引
额定电压(V)
空载电流(A/7.4V)
空载转速(rpm/7.4V)
整机重量(g)
整机平衡度(mg)
保存温度(℃)
保存湿度(%)
整机高度(mm)
电机高度(mm)
安装孔位(mm)
Motor Guide
整机耐压(DC)
使用环境温度(℃)
整机外径(mm)
2-M1.7, hole spacing(孔距) 12.5mm
28 # silicone wire (red, yellow, black)
28#硅胶线(红黄黑)
70mm ± 5mm (including 2.0 terminals)
70mm±5mm(含2.0端子)
7.4V
≤0.6A
25900±5%
180mΩ±3%
15.4g
DC500V(3S)
≤10mg
-10℃ - 65℃
-10℃ - 50℃
≤85%
29.5±0.2mm
22.5±0.2mm
16.5±0.1
Advertisement
Related Manuals for udir/c UCX24-E009
Summary of Contents for udir/c UCX24-E009
- Page 1 UCX24-E009 Motor Guide 电机指引 Data 参数 Rated voltage (V) 7.4V 额定电压(V) No load current (A/7.4V) ≤0.6A 空载电流(A/7.4V) No-load speed (rpm/7.4V) 25900±5% 空载转速(rpm/7.4V) Internal resistance of motor (m )(environment temperature 25 °C) 180mΩ±3% 电机内阻(mΩ)(环境温度:25℃) Total weight(g) 15.4g 整机重量(g) Whole machine withstand voltage (DC) DC500V(3S) 整机耐压(DC)
