1/16 Full proportion high-performance 4WD racing car
Operating
Instructions
UD1601PRO
This product is suitable for users over 14 years old.
Please read this instruction manual carefully befores use.
Our company's products are improving all the time,design and specifications are
Important
subject to change without notice. All the information in this manual has been
carefully checked to ensure accuracy, if any printing errors, our company reserve
Notice
the final interpretation right.
UD1602PRO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UD1601PRO and is the answer not in the manual?

Questions and answers

Summary of Contents for udir/c UD1601PRO

  • Page 1 1/16 Full proportion high-performance 4WD racing car Operating Instructions UD1601PRO UD1602PRO This product is suitable for users over 14 years old. Please read this instruction manual carefully befores use. Our company's products are improving all the time,design and specifications are Important subject to change without notice.
  • Page 2 Demo video Operation guide download...
  • Page 3 THANK YOU ● Thank you for choosing this product. The remote control model is designed to be fun to drive and uses high quality parts to improve durability and performance. The instruction manual you are reading is to make the product easier to understand and explain more thoroughly. We hope you enjoy this remote control model car.
  • Page 4: Product Configuration

    7) Different types of batteries or old and new batteries should not be mixed; 8) DO NOT short circuit any terminals; 9) DO NOT short circuit, decompose or put the battery into fire; 10) Please use the attached special charger to charge the battery. Product Configuration UD1601PRO UD1601PRO UD1602PRO UD1602PRO Body...
  • Page 5 Guidance before operation Preparation of remote control model 1> UD1601PRO Summary 1601-001 Body assembly 1601-002 Body clips 1601-003 Headlight group 1603-005 Tire 1603-004 3mm Locknut 1601-009 Rear shock 1601-008 MT2401 Rear shock Motor tower 1601-008 1601-014 Front shock 1601-016 Rear bumper...
  • Page 6 UD1602PRO Summary 1602-001 Body assembly 1601-002 Body clips 1601-003 1601-005 Headlight group Tire 1601-004 3mm Locknut 1602-009 Rear shock MT2401 1602-008 Motor Rear shock tower 1601-016 Upper 1602-008 1602-014 chassis Rear bumper Front shock tower S1701 Steering servo 1602-009 Front shock 1601-012 1601-013 Li-ion Battery...
  • Page 7 Battery charging 1>-1 The battery contains less power when leaving the factory, so it must be charged and saturated before use. Connect the attached charger with the model battery charging input port, and then connect other USB output port charging, the charging indicator is ashing, and the indicator is always on after charging. Do not put the battery in th model when charging.
  • Page 8 Assembly of model battery 1>-3 Put the battery in the slot Pull out the clips Remove the battery hold-down Battery hold-down reset Clips reset The battery output port the ESC input port Press for 1 second to turn on the power. The lights flash and enter the frequency correctly connected.
  • Page 9 Preparation of transmitter 2> (Summary) Default steering wheel direction Transmitter function main interface Turn right Turn left Default throttle trigger Power switch direction Backward Throttle speed limit Car lights control switch Forward button The car lights color mode can be switched and the car lights can be switched off.
  • Page 10: Operational Guidance

    Operational guidance Frequency matching 1> Place the model on level ground Do not touch the throttle trigger when turning on thepower of the transmitter. Turn on the power of the transmitter, and Consistent direction the red indicator light will flash quickly. After the car power is turned on, the transmitter and the car will carry out automatic frequency matching.
  • Page 11 Turn left and move forward Throttle trigger Steering wheel Go forward Turn left Turn right and move forward Throttle trigger Steering wheel Go forward Turn right Turn left and move backward Turn right and move backward Throttle trigger Steering wheel Throttle trigger Steering wheel Go backward...
  • Page 12 Model car speed control 3> By switching the three gears of the throttle speed limit switch, three different maximum speeds of the car can be set. Low speed mode: Throttle output limited to 50%. Medium speed mode: Throttle output limited to 75%. High speed mode: 100% throttle output.
  • Page 13 1. There is no ESP function when the remote control car retreats. 2. When the remote control car is moving forward, it is necessary to pull the throttle trigger backward to reach more than 30% of the stroke before the gyroscope starts to work.
  • Page 14: Replacement Of Parts

    Weak signal alarm 5> When the signal is weak or the signal is interrupted, the red indicator of the transmitter will flash quickly. Please operate within the effective control distance to avoid accidents. Low battery alarm 6> When the battery of the transmitter is low, the red indicator of the transmitter will flash slowly. When the car battery is low, the transmitter green indicator light flashes.
  • Page 15 Replace the tires 2> Use the hexagon nut wrench to take Hexagon nut wrench out the nut fixing the tire and remove the old tires. Put on new tires. Parts exploded view Left(Right) front wheel component 1601-026 1601-024 1601-018 1601-022 1601-005 1601-017 1601-021...
  • Page 16 Left (right) rear wheel components 1601-050 1601-005 1601-026 1601-027 1601-029 1601-017 1601-021 1601-018 1601-027 1601-004 1601-022 1601-016 1601-051 1601-024 Differential assembly 1601-029...
  • Page 17 Front (rear) shock absorber components 1601-009 / 1602-009 Steering system components 1601-030 1601-030 1601-057 S1701 1601-032 1601-024 1601-033 1601-024 1601-019 1601-048 1601-031 1601-033 1601-019...
  • Page 18 Screws assembly diagram UD1601PRO Bottom view 1601-024 1601-024 1601-054 1601-054 1601-054 1601-054 1601-056 1601-056 1601-054 1601-054 1601-053 1601-054 1601-053 1601-054 1601-024 1601-024 Top view 1601-019 1601-024 1601-024 1601-049 1601-062 1601-054 1601-054 1601-056 1601-054 1601-054 1601-062 1601-060 1601-024 1601-024 1601-019 1601-055...
  • Page 19 Screws assembly diagram UD1602PRO Bottom view 1601-024 1601-024 1601-054 1601-054 1601-056 1601-054 1601-056 1601-054 1601-056 1601-054 1601-054 1601-053 1601-054 1601-056 1601-053 1601-054 1601-024 1601-024 Top view 1601-019 1601-024 1601-024 1601-049 1601-062 1601-054 1601-054 1601-056 1601-054 1601-054 1601-062 1601-024 1601-060 1601-024 1601-019 1601-055 1601-055...
  • Page 20: Product Maintenance

    Product maintenance When not in use, remove the battery from the Please clean the sediment and dirt on the car model and transmitter. before entering the warehouse. Apply lubricating oil to external metal parts. Please separate the car and battery when not in use.
  • Page 21 Buyable accessories 1601-001 1602-001 1601-002 1601-003 Body assembly Body assembly Body clips Headlight group 1601-004 1601-005 1601-005 MT2401 3mm Locknut Tire Tire Brushless Motor S1701 1601-008 1602-008 1601-009 Steering servo Front & Rear shock Front & Rear shock Front & Rear shock tower assembly tower assembly assembly...
  • Page 22 1601-016 1601-017 1601-018 1601-019 Wheel adapters 2.5×10mm Pivot balls Ball bearing(8×4×3mm) Front & Rear wheel carriers assembly 1601-020 1601-021 1601-022 1601-023 Shaft(1.8×6.8mm) Metal front CVD shafts Steering linkage Ball bearing(12×8×3.5mm) 1601-024 1601-025 1601-026 1601-027 Metal Rear Dogbones + 2.5×12mm Pivot balls Shaft(2.5×32mm) Suspension arms (front) Metal Rear Wheel shafts...
  • Page 23 1601-040 1601-041 1601-042 1601-043 Main propeller shaft Taillight group Charger Bulkhead tie bars(rear) 1601-044 1601-045 1601-046 1601-047 Socket nut wrench Hex wrench Transmitter Cross screwdriver 1601-048 1601-049 1601-050 1601-051 2.5×11.8mm PM 2.5×5mm PM Screws 2×13mm PM 2.5×16.5mm PM Shoulder screws Screw pin set Screw pin set 1601-052...
  • Page 24: Fcc Note

    FCC Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interferencein a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
