udir/c UD1201 Operating Instructions Manual page 22

P12-039
Main spur gear
P12-043
Bind Velcro
M01-003
Hexagon socket head cap Hexagon socket head cap
tapping screw tapping screw
ø2.6×10mm HB
M01-012
Hexagon socket countersunk
head tapping screw
ø2.6×8mm KB
M01-017
Hexagon socket button head
tapping screw
ø2.6×8mm TB
P12-040
Body clips × 4
M01-004
Hexagon socket head cap
tapping screw
ø2.6×12mm HB
M01-013
Hexagon socket countersunk
head tapping screw
ø2.6×15mm KB
M01-019
Hexagon socket button head
machine screw
ø2.5×12mm TM
P12-041
Main driveshaft
ø6.25×216mm
M01-008
Hexagon socket head cap
machine screw
ø2.5×10mm HM
M01-014
Hexagon socket countersunk
head tapping screw
ø2.5×8mm KM
M01-020
Hexagon socket button head
machine screw
ø2.5×15mm TM
22
P12-042
Front wheel seat cover
M01-010
Hexagon socket head cap
machine screw
ø3×8mm HM
M01-016
Hexagon socket button head
tapping screw
ø2.6×6mm TB
M01-022
Hexagon socket button head
machine screw
ø3×15mm TM
