UD1805 / UD1805PRO / UD1806 / UD1806PRO
1/18 UDISPORT DESERT RACING BUGGY
OPERATING
INSTRUCTIONS
FULL PROPORTIONAL REMOTE CONTROL UDIRACING SERIES
Our company's products are improving all the time,design and specifications are subject to
Important
change without notice. All the information in this manual has been carefully checked to ensure
Notice
accuracy, if any printing errors, our company reserve the final interpretation right.
This product is suitable for users over 14 years old.
Please read this instruction manual carefully befores use.
V1.0
Advertisement
Related Manuals for udir/c UD1805
Summary of Contents for udir/c UD1805
- Page 1 UD1805 / UD1805PRO / UD1806 / UD1806PRO 1/18 UDISPORT DESERT RACING BUGGY OPERATING INSTRUCTIONS FULL PROPORTIONAL REMOTE CONTROL UDIRACING SERIES V1.0 This product is suitable for users over 14 years old. Please read this instruction manual carefully befores use. Our company's products are improving all the time,design and specifications are subject to Important change without notice.
- Page 2 THANK YOU ● Thank you for choosing this product. The remote control model is designed to be fun to drive and uses high quality parts to improve durability and performance. The instruction manual you are reading is to make the product easier to understand and explain more thoroughly.
- Page 3 WARNING Before Operation ● Read the instruction manual in detail, or ask for the person with experience in operation, and read with the guardian if necessary. ● Make sure all screws and nuts are properly tightened. ● The remote control and the vehicle should always use the battery with saturated power to avoid losing control of the model.
-
Page 4: Product Maintenance
Product maintenance When not in use, remove Please remove the sediment the battery from the and dirt on the car model and transmitter. completely and must be kept dry after play. Apply lubricating Please separate oil to external the car and battery metal parts. - Page 5 Model Car Summary 1805-006 1805-014 1805-012 1806-003B 1601-015 1805-004 Power switch 1805-007 1601-007 1805-006 1601-013 1601-011 1805-007 1601-035 1601-012 1805-010 1805-008 1805-011 1805-009 1805-015 1601-016 1805-003 1601-004...
- Page 6 1806-003A 1805-006 1806-003A 1805-005 S1701 ESC01W Power switch 1805-002 1805-001 1806-001 1806-002...
-
Page 7: Electronic Speed Controller
Electronic speed controller 1601-011 Antenna Headlight Steering servo Taillight Model Battery Motor ESC01W Taillight Steering servo Model Battery Motor Power switch Headlight Antenna... - Page 8 Preparation of transmitter Transmitter function Default steering main interface wheel direction Turn left / Turn right Power switch Car lights control button Default throttle trigger The car lights color mode can be switched and the car lights can direction be switched off. Forward / Backward / Brake Throttle speed limit switch Low speed mode:...
- Page 9 Adjustment of gyroscope action ratio This product has the function of ESP car stability system, which can effectively correct the car attitude and direction when the car skids or loses control. The function and sensitivity of the car gyroscope sensor can be adjusted through the ESP knob of the transmitter. The action ratio The action ratio decreased...
- Page 10 Assembly of the transmitter battery Battery Cover Note Direction. 1.5V×4 AAA Batteries(not included) Open battery cover at the bottom of transmitter. Install batteries. Follow the direction of batteries designated in the inside of the battery box. Model Battery charging The battery contains less power when leaving the factory, Connect the attached charger with the model battery charging so it must be charged and saturated before use.
-
Page 11: Operational Guidance
2) Pull out the clips, and remove the battery hold-down. Output 3) Put the battery into the battery input port port Model Battery compartment, Battery hold-down reset clips reset and then connect 4) Reset the bodyshell with the ESC. Operational guidance Frequency matching 1>... - Page 12 1601-011 Power on method Press for 2 second to turn on the power. The lights flash and enter the frequency matching state. Press for 2 second to turn off the power. 1601-011 ESC01W Power on method Press for 2 second to turn on the power. The lights flash and enter the frequency matching state.
- Page 13 Steering wheel Steering wheel Turn left Turn right Turn left and move forward Turn right and move forward Throttle trigger Steering wheel Throttle trigger Steering wheel Go forward Turn left Go forward Turn right Turn left and move backward Turn right and move backward Throttle trigger Steering wheel Throttle trigger...
-
Page 14: Parts Exploded View
Parts exploded view Installation of wheels Hexagon nut wrench 1601-016 1601-022 Wheel 1601-004 Wheel Use the hexagon nut wrench to take out the nut fixing the tire(1601-004) and remove the old tires. Put on new tires. Front and rear shock absorbers... - Page 15 Assembly of front suspension arm 1601-050 1805-011 1601-063 1805-015 1601-051 1601-022 1805-009 1601-021 1805-011 1601-063 1601-026 1805-009 1805-010 1601-017 1601-019 Assembly of rear suspension arm 1805-012 1601-050 1601-050 1805-015 1601-021 1601-022 1805-009 1601-026 1805-012 1601-017 1601-051...
- Page 16 Assembly of front bumper 1601-034 1805-006 1601-064 1601-055 1601-055 1601-035 1601-039 1805-008 1601-056 1601-056 1601-062 Assembly of rear bumper 1805-006 1601-034 1601-055 1601-042 1601-035 1601-039 1805-008 1601-056...
- Page 17 Assembly of steering servo 1601-024 1601-032 Steering servo 1601-024 1601-031 1601-031 1601-030 1601-031 1601-033 Assembly of front(rear) differentials 1601-029A...
- Page 18 Rear sopiler 1805-014 1601-002 1805-014 1601-066 1805-006 Upper chassis 1601-056 1805-006 1601-060 1601-049 1805-006 1601-034 1601-034 1601-015 1601-054 1601-054 1601-054 1601-062 1601-024 1601-056 1601-024 1601-013 1601-060...
- Page 19 Main propeller shaft system 1601-036 1601-017 1601-021 1601-041 1601-038 1601-017 Assembly of chassis 1601-056 1601-056 1601-054 1601-062 1601-056 1601-053...
- Page 20 Buyable accessories 1805-001 1806-001 1601-002 1805-002 Body assembly Body assembly Body clips × 4 Headlight group(UD1805) 1806-002 1805-003 1806-003A 1806-003B Headlight group(UD1806) Wheel × 2 Wheel × 2 Wheel × 2 1805-004 1805-005 1601-007 S1701 Motor assembly(390) Motor assembly(Brushless) Steering servo(390 Motor)
- Page 21 1601-016 1805-009 1805-010 1805-011 Wheel adapters × 4 Front & Rear wheel Adjustable steering linkage Suspension arms (front) carriers assembly 1601-030 1805-015 1805-012 1601-029A Driveshaft assembly × 2 Suspension arms (rear) Differential assembly Servo saver 1601-031 1601-032 1601-034 1601-035 Chassis Steering bellcrank Rudder connecting rod Differential housing...
- Page 22 UA37 1805-014 Transmitter Rear sopiler assembly 1601-045 1601-046 1601-047 Cross screwdriver Hexagon nut wrench Hex wrench 2-4mm 1601-048 1601-049 1601-050 1601-051 Ø2.5×11.8mm PM Ø2.5×5mm PM Ø2×13mm PM Ø2.5×16.5mm PM Shoulder screws ×8 Screws ×8 Screw pin set ×8 Screw pin set ×8 1601-052 1601-053 1601-054...
- Page 23 1601-062 1601-063 1601-064 1601-065 Brushless motor mounts Ø2.3×6mm PB Ø4×6.6mm PM Ø2×8mm PB Ø3×8mm KM Screws ×8 Shoulder screws ×8 Screws ×8 Screws ×8 1601-066 Ø2.6×8mm PB Screws ×8 1601-004 1601-017 1601-021 Hex flanged nylon Ø8×Ø4×3mm Ø12×Ø8×3.5mm insert lock nut ×4 Ball bearing ×4 Ball bearing ×4 1601-019...
- Page 24 FCC Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interferencein a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
