OPERATING
INSTRUCTIONS
Full proportion high-performance 4WD racing car
Our company's products are improving all the time,design and specifications are subject to
Important
change without notice. All the information in this manual has been carefully checked to ensure
Notice
accuracy, if any printing errors, our company reserve the final interpretation right.
1/16 Series
This product is suitable for users over 14 years old.
Please read this instruction manual carefully befores use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1/16 Series and is the answer not in the manual?

Questions and answers

Related Manuals for udir/c 1/16 Series

Summary of Contents for udir/c 1/16 Series

  • Page 1 1/16 Series OPERATING INSTRUCTIONS Full proportion high-performance 4WD racing car This product is suitable for users over 14 years old. Please read this instruction manual carefully befores use. Our company's products are improving all the time,design and specifications are subject to Important change without notice.

  • Page 3: Battery Safety

    THANK YOU ● Thank you for choosing this product. The remote control model is designed to be fun to drive and uses high quality parts to improve durability and performance. The instruction manual you are reading is to make the product easier to understand and explain more thoroughly.

  • Page 4: Product Maintenance

    ● The product contains small and sharp parts. Keep away from children. ● Cutters, nippers and screwdrivers need careful handling. ● DO NOT put the model in high temperature, humidity and direct sunlight. ● The model must stop immediately and check for the reasons when it is operating abnormal. ●...

  • Page 5: Battery Charging

    Guidance before operation Battery charging 1>-1 The battery contains less power when leaving the factory, Connect the attached charger with the model battery charging so it must be charged and saturated before use. input port, and then connect other USB output ports. When charging, the charging indicator is flashing, and the indicator is always on after charging.
  • Page 6 Start up 1>-3 The battery output port and the ESC Press for 1 second to turn on the power. The lights input port are correctly connected. flash and enter the frequency matching state. Press for 2 second to turn off the power. After the battery is assembled, reset the body.

  • Page 7: Operational Guidance

    Assembly of the transmitter battery 2>-1 Battery Cover 1.5V×4 AA Alkaline Batteries Note Direction. Open battery cover at the bottom of transmitter. Install batteries. Follow the direction of batteries designated in the inside of the battery box. Operational guidance Frequency matching 1>...
  • Page 8 Go forward Go backward Throttle trigger Throttle trigger Turn left and move forward Throttle trigger Steering wheel Go forward Turn left Turn right and move forward Throttle trigger Steering wheel Go forward Turn right Turn left and move backward Turn right and move backward Throttle trigger Steering wheel Throttle trigger...
  • Page 9 Low speed High speed Brake/Backward Pull the throttle trigger back The throttle trigger is pulled to When the car is moving forward, the throttle trigger gently and the car will move the maximum, and thecar moves is pushed forward and the car stops moving. After forward slowly.

  • Page 10: Steering Trim

    The action ratio The action ratio Adjustment of decreased increases gyroscope action ratio This product has the function of ESP car stability system, which can effectively correct the car attitude and direction when the car skids or loses control. The function and sensitivity of the car gyroscope sensor can be adjusted through the ESP knob of the transmitter. When the front wheel When the front wheel Steering trim...

  • Page 11: Replacement Of Parts

    Weak signal alarm 5> When the signal is weak or the signal is interrupted, the red indicator of the transmitter will flash quickly. Please operate within the effective control distance to avoid accidents. Low battery alarm 6> When the battery of the transmitter is low, the red indicator of the transmitter will flash slowly. When the car battery is low, the transmitter green indicator light flashes.
  • Page 12 Replace the tires 2> Use the hexagon nut wrench to take out the nut fixing the tire and remove the old tires. Put on new tires. Hexagon nut wrench Parts exploded view 3> Left(Right) front wheel component 1601-026 1601-024 1601-018 1601-022 1601-005 1601-017...
  • Page 13 Left (right) rear wheel components 1601-050 1601-005 1601-026 1601-027 1601-029 1601-017 1601-021 1601-018 1601-027 1601-004 1601-022 1601-016 1601-051 1601-024 Differential assembly 1601-029...
  • Page 14 Front (rear) shock absorber components 1601-009 Steering system components 1601-030 1601-030 1601-057 1601-007 1601-032 1601-024 1601-033 1601-024 1601-019 1601-048 1601-031 1601-033 1601-019...
  • Page 15 Screws assembly diagram Bottom view 1601-024 1601-024 1601-054 1601-054 1601-054 1601-062 1601-054 1601-056 1601-054 1601-054 1601-053 1601-054 1601-053 1601-054 1601-024 1601-024 Top view 1601-019 1601-024 1601-024 1601-049 1601-062 1601-054 1601-054 1601-056 1601-054 1601-062 1601-060 1601-024 1601-024 1601-019 1601-055 1601-055 Front view Rear view...
  • Page 16 Buyable accessories 1601-002 1601-003 1601-004 1601-005 Body clips Headlight group 3mm Locknut Tire 1601-006 1601-007 1601-009 1603-010 Motor Steering servo Front & Rear shock assembly Front bumper assembly 1601-011 1601-012 1601-013 1601-015 2.4GHz Integrated ESC Li-ion Battery Battery hold-down Upper chassis 1601-016 1601-017 1601-018...
  • Page 17 1601-023 1601-024 1601-025 1601-026 Metal front CVD shafts 2.5×12mm Pivot balls Suspension arms (front) Shaft(2.5×32mm) 1601-027 1601-028 1601-029 1601-030 Metal Rear Dogbones + Suspension arms (rear) Differential assembly Servo saver Metal Rear Wheel shafts 1601-031 1601-032 1601-033 1601-034 Steering bellcrank Rudder connecting rod Shaft(2.5×21mm) Differential housing...
  • Page 18 1601-048 1601-049 1601-050 1601-051 2.5×11.8mm PM 2×13mm PM 2.5×16.5mm PM 2.5×5mm PM Screws Shoulder screws Screw pin set Screw pin set 1601-047 1601-052 1601-053 1601-054 Hex wrench 2.5×7mm KM Screws 2.5×10mm KM Screws 2.3×8mm PB Screws 1601-055 1601-056 1601-057 1601-058 2×10mm PB Screws 2.5×14mm PB Screws 2.3×14mm PB Screws...

  • Page 19: Fcc Note

    FCC Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interferencein a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 20 Demo video Operation guide download Manufacturer: UDIRC TECHNOLOGY CO., LTD Address: Guangfeng Industrial Zone, Guangyi Street, Chenghai District, Shantou City, Guangdong Province, CN...
