udir/c UD1201 Operating Instructions Manual page 9

This product has the function of ESP car stability system, which can effectively correct the car attitude and direction when the car skids
or loses control. The function and sensitivity of the car gyroscope sensor can be adjusted through the ESP knob of the transmitter.
The steering range adjustment knob can be used to adjust the left and right steering angle of the car.
When the steering wheel is in the center position, if the car can not drive in a straight line, please use the steering trim knob to adjust
and correct the left and right directions of the front wheels.
Adjustment of gyroscope action ratio
The action ratio
decreased
Steering range adjustment
Minimum
steering
angle
Steering trim
When the front wheel
is left, the knob rotates
to the right.
The action ratio
increases
Maximum
steering
angle
When the front wheel
is right, the knob
rotates to the left.
09
