4.2. ATEX / IECEx / UKEX certification
The EC-Type Examination Certificates:
DEMKO 14ATEX4786493904X, IECEx ULD14.0004X and
UL21UKEX2131X have been issued by UL. This confirms
compliance with the European ATEX Directive 2014/34/EU for
Group II, Category 3G/D equipment.
Community Mark and subject to local codes of practice, may
be installed in any of the EEA member countries. This
instruction sheet describes installations which conform to the
current issue of EN60079-14/IEC60079-14
Installation in Hazardous Areas; EN60079-10-1 / IEC 60079-
10-1 Explosive Atmospheres - Classification of Areas.
Explosive Gas Atmospheres; EN60079-10-2 / IEC 60079-10-2
Explosive Atmospheres - Classification of Areas. Explosive
Dust Atmospheres. When designing systems for installation
outside the UK, the local Code of Practice should be
consulted.
EN IEC 60079-0:2018 / IEC60079-0:2017 (Ed 7):
Explosive Atmospheres - Equipment. General Requirements
EN IEC 60079-7:2015 +A1:2018 / IEC 60079-7:2018 (Ed. 5.1):
Explosive Atmospheres - Equipment Protection by Increased
Safety "e"
EN 60079-31:2014 / IEC 60079-31:2013 (Ed 2):
Explosive Atmospheres - Equipment Dust Ignition Protection by
Enclosure "t"
D2XC1X05 : Ex ec IIC T2 Gc (Ta -40ºC to +50°C)
Ex tc IIIC T90ºC Dc (Ta -40ºC to +50°C)
D2XC1X10 : Ex ec IIC T1 Gc (Ta -40ºC to +50°C)
Ex ec IIC T2 Gc (Ta -40ºC to +40°C)
Ex tc IIIC T110ºC Dc (Ta -40ºC to +50°C)
4.3. NEC & CEC Ratings
NEC & CEC Class / Division Ratings for US and Canada
UL 121201-2021 (Ed. 9)
CAN/CSA C22.2 No. 213-17 (Ed. 3)
D2XC1: Class I Div 2
X05 Class I Div 2
Class I Div 2
Class II Div 2
Class III Div 1&2
D2XC1: Class I Div 2
X10 Class I Div 2
Class II Div 2
Class II Div 2
Class III Div 1&2
Installation must be carried out in compliance with the National
Electric Code / Canadian Electric Code
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
Document No. D189-00-501-IS
The unit carries the
Standards
Ratings
Standards
Ratings
ABCD T2B Ta -40ºC to +70ºC
ABCD T2C Ta -40ºC to +55ºC
ABCD T2D Ta -40ºC to +40ºC
FG T5 Ta -40ºC to +50ºC
Ta -40ºC to +50ºC
ABCD T1 Ta -40ºC to +70ºC
ABCD T2 Ta -40ºC to +50ºC
FG T4A Ta -40ºC to +50ºC
FG T5 Ta -40ºC to +40ºC
Ta -40ºC to +50ºC
Issue 11
Certificate No.
ATEX Mark, Equipment
Group and Category:
CE Marking
Electrical
UKCA Marking
NEC Class / Zone Ratings US
UL 60079-0 (Ed. 7):
Explosive Atmospheres - part 0: Equipment - General
Requirements
UL 60079-7 (Ed. 5):
Explosive Atmospheres - Equipment Protection by Increased
Safety "e"
UL 60079-31 (Ed. 2)
Explosive Atmospheres - Equipment Dust Ignition Protection
by Enclosure "t"
D2XC1: Class I, Zone 2 AEx ec IIC T2 Gc (Ta -40ºC to +50°C)
X05 Zone 22 AEx tc IIIC T120°C Dc(Ta -40ºC to +50°C)
D2XC1: Class I, Zone 2 AEx ec IIC T1 Gc(Ta -40ºC to +50°C)
X10 Class I, Zone 2 AEx ec IIC T2 Gc(Ta -40ºC to +40°C)
Zone 22 AEx tc IIIC T120°C Dc(Ta -40ºC to +50°C)
Installation must be carried out in compliance with the National
Electric Code.
CEC Class / Zone Ratings Canada
CAN/CSA C22.2 No. 60079-0 (Ed. 4) 02/2019
Explosive Atmospheres - Part 0: Equipment - General
Requirements
CAN/CSA C22.2 No. 60079-7 (Ed. 2)
Explosive Atmospheres - Equipment Protection by Increased
Safety "e"
CAN/CSA C22.2 No. 60079-31 (Ed. 2)
Explosive Atmospheres - Equipment Dust Ignition Protection by
Enclosure "t"
D2XC1X05:
D2XC1X10:
Installation must be carried out in compliance with the Canadian
Electric Code
20-08-22
DEMKO 14 ATEX 4786493904X
IECEx ULD 14.0004X
UL21UKEX2131X
Standards
Ratings
Standards
Rating
Ex ec IIC T2B Gc X (Ta -40ºC to +50°C)
Ex ec IIC T2C Gc X (Ta -40ºC to +45°C)
Ex tc IIIC T120°C Dc (Ta -40ºC to +50°C)
Ex ec IIC T1 Gc X (Ta -40ºC to +50°C)
Ex ec IIC T2 Gc X (Ta -40ºC to +40°C)
Ex tc IIIC T120°C Dc (Ta -40ºC to +50°C)
