Key Digital iSync HD Quick Reference Manual page 7

Page F
iSync HD / iSync Pro Quick Reference Guide
MENU - Page F
UP and DOWN arrows navigate to each SUB-MENU entry
LEFT and RIGHT arrows select the desired value for SUB-MENU entry
To Set Up Input &
MENU
Output Color Space
First, select the Color
Space you want to
adjust:
› HDMI Input Color Space
› HDMI Output Color
Space
› HDMI Output Setup
›
Analog Output Setup
Then, set the Color Space you
want:
›
YPbPr
› RGB
›
(DEFAULT) / Auto
›
YCbCr
› RGB
›
(DEFAULT) / Auto
›
(DEFAULT) / HDMI - DVI
›
(DEFAULT) / YCbCr - RGBHV
iSync HD / iSync Pro Quick Reference Guide
MENU - Page G
UP and DOWN arrows navigate to each SUB-MENU entry
LEFT and RIGHT arrows select the desired value for SUB-MENU entry
To Display a
MENU
Test Pattern
First, select the Test
Pattern for the Input or
the Output of the iSync:
› Input Pattern
› Output Pattern
Page G
Then, choose the desired Test
Pattern:
› ( DEFAULT ) / Normal Display
›
Horizontal Ramp
› Color Bars
› ( DEFAULT ) / Normal Display
›
Horizontal Ramp
› Color Bars
› Cross Hatch
›
Gray Scale
› White Window
›
Wide Horizontal Ramp
› Wide Vertical Ramp
