iSync HD / iSync Pro Quick Reference Guide
2. Confi guring your iSync HD [Pro]
Once your preferred components have been connected to the appropriate Input and Output ports
using the proper cabling and connectors, you are ready to begin confi guring your iSync HD [Pro] for
operation in your installation.
To confi gure your unit, use either the on-board navigating keys located on the face of the unit, or the
supplied IR remote control (with its convenient "Hot Buttons") to directly access and adjust basic
picture quality parameters; and associate Audio components to a specifi c Video source.
View menu headings and associated parameter adjustments on the convenient LCD screen
on the face of the unit:
1. Press the MENU button: See the input and output screen resolutions.
2. Press the MENU button again: The desired output screen resolution is ready to be selected.
3. Press the RIGHT or LEFT arrow buttons to select desired screen resolution.
4. Press the UP or DOWN arrow button to select the next parameter.
5. Press the RIGHT or LEFT arrow button to change the selected parameter setting.
➔ RIGHT & LEFT arrows will scroll through the available settings of each selected parameter in
a continuous loop.
➔ Function selection is voided when no key is depressed for more than 30 seconds.
IN: 720x480p @ 60Hz
OUT: 720x480p @ 60Hz
[ OUT RESOLUTION ]
< 1280x720p @ 60Hz >
ASPECT
< FULL SCREEN >
IN COLOR SPACE
< AUTO >
OUT COLOR SPACE
< RGB >
Pressing the MENU button once will display the current status of the Video formats present at the
input and output of the iSync HD [Pro] on the on-board LCD screen.
Pressing the MENU button a second time will display the last heading accessed on the MENU tree
and prompt the user, by means of left and right pointing arrows bracketing that heading, to access
the sub-menu.
The LEFT and RIGHT buttons will scroll through the content of an individual sub-menu associated with a
particular parameter, in a continuous loop, until such time that the user either exits the system by pressing
the MENU button or resumes scrolling through the SUB-MENU using the UP and DOWN buttons.
Successively pressing either the UP or DOWN
headings tabulated in the SUB-MENU column.
Pressing either the LEFT or RIGHT button will access items listed in the SUB-MENU.
Examples
Select desired Output Resolution,
such as 1280 x 720p @ 60 Hz
Select desired Aspect Ratio Conversion,
such as Full Screen, Letterbox, H-Zoom, etc.
Select desired HDMI Input Color Space,
such as Automatic
Select desired HDMI Output Color Space,
such as RGB
button will access, in a continuous loop, all the
iSync HD / iSync Pro Quick Reference Guide
3. Audio / Video Associations
For proper operation of your iSync HD [Pro] unit, you must associate each Audio component to a
specifi c Video source.
MENU SUBMENU DESCRIPTION
1. HDMI1 Associate HDMI1with audio input # ( 0 ~ 11 )
2. HDMI2 Associate HDMI2 with audio Input # ( 0 ~ 11 )
3. Component1 Associate Component1 with audio input # ( 0 ~ 11 )
4. Component2 Associate Component2 with audio input # ( 0 ~ 11 )
5. Component3 Associate Component3 with audio input # ( 0 ~ 11 )
6. Composite1 Associate Composite1 with audio input # ( 0 ~ 11 )
7. Composite2 Associate Composite2 with audio input # ( 0 ~ 11 )
8. Composite3 Associate Composite3 with audio input # ( 0 ~ 11 )
9. S-Video1 Associate S-Video1 with audio input # ( 0 ~ 11 )
10. S-Video2 Associate S-Video2 with audio input # ( 0 ~ 11 )
11. Default Setting up Default for all properties of the A/V association
For Example, Stereo Input 1 can be associated with HDMI Input 2; Coax Input 3 can be
associated with Component Input #2. Use the table below as an example guide to map
your associations.
VIDEO INPUT AUDIO INPUT
1. HDMI1 1. Stereo #1
2. HDMI2 2. Stereo #2
3. Component #1 3. Stereo #3
4. Component #2 4. Stereo #4
5. Component #3 5. Coaxial #1
6. Composite #1 6. Coaxial #2
7. Composite #2 7. Coaxial #3
8. Composite #3 8. Coaxial #4
9. S-Video #1 9. Optical #1
10. S-Video #2 10. Optical #2
11. None
You must make "Audio / Video"
associations, to link each Video Input to the
desired source of Audio
1. Scroll through the MENU until you reach
"TO ADJUST A/V ASSOCIATION"
2. First, use the UP and DOWN
pushbuttons (at the SUB-MENU) to
select the Video Input of interest
3. Then, use the LEFT and RIGHT
pushbuttons to associate the appropriate
Audio source with that Video Input
