iSync HD / iSync Pro Quick Reference Guide
4. MENU
As you scroll through the MENU [by stepping through using the MENU pushbutton] and each SUB-
MENU [by stepping through using the UP
desired MENU item] of your iSync HD [Pro] unit, you can observe the status on the front-panel LCD.
Then, specifi c SUB-MENU settings can be made using the LEFT
pushbuttons.
The entire Menu structure is provided here for your convenience.
UP and DOWN arrows navigate to each SUB-MENU entry
MENU
To Select Your To Adjust
Input Video Picture
See See
Page A Page B
To Adjust To Adjust
Hidden Hot Keys Factory Default
See See
Page J Page I
and DOWN arrow pushbuttons once you are at the
and RIGHT
To Adjust To Adjust A/V To Adjust Output
Screen Association Resolution
See See See
Page C Page D Page E
To Adjust To Adjust To Adjust
Test Pattern Set-Up
See See See
Page H Page G Page F
MENU - Page A
UP and DOWN
arrow
MENU
iSync HD / iSync Pro Quick Reference Guide
arrows navigate to each SUB-MENU entry
To Select
Your Input Video
› HDMI1
›
HDMI2
›
Component #1
› Component #2
›
Component #3
› Composite #1
›
Composite #2
›
Composite #3
› S-Video #1
›
S-Video #2
Page A
