KD-VP6 & VP8 Operating Instructions
521 East 3rd Street, Mount Vernon, NY 10553
::
::
Phone
914.667.9700 Fax
914.668.8666
::
Web
www.keydigital.com
Key Digital
, led by digital video pioneer Mike Tsinberg,
®
develops and manufactures high quality, cutting-edge
technology solutions for virtually all applications where
high quality video imaging is important. Key Digital
is at the forefront of the video industry for Home
Theater Retailers, Custom Installers, System Integrators,
Broadcasters, Manufacturers, and Consumers. We
provide total video system solutions because we
know and help drive the technology, the industry, the
business, and all the latest up-and-coming standards.
But most of all, we know exactly what you need for your
unique application - the right solution.
Rev 0 – December 2006
KD-VP6
Digital Video Processor
Operating Instructions
KD-VP6
®
Key Digital
KD-VP Spider Series
®
480i, 480p and PAL 576i, 576p analog video sources to component video. Additionally,
the KD-VP8 includes HDMI and HDMI over CAT 5 outputs. KD-VP's feature IAS
Auto Sense signal detection and switching, pushbutton control, status-monitoring LED's
and RS-232 and IR remote control. KD-VP processors are expandable, individually
addressable, and the KD-VP8 is DVI-D compatible when used with Key Digital
and cables. Spider Series
and test criteria to produce crystal-clear, pristine picture quality.
KD-VP8
Digital Video Processor
KD-VP8
Video Processors convert standard definition NTSC
™
products are engineered to meet rigorous Key Digital
™
Intelligent
™
adapters
®
design
®
