Key Digital HD Leeza KD-HD1080P Quick Setup Manual

Video processor
Hide thumbs Also See for HD Leeza KD-HD1080P:

Advertisement

Quick Links

HD Leeza
Key Digital

Quick Setup Guide

Have a question or a technical issue with your HD Leeza set-up?
I
Call the Key Digital
I
E-mail the Key Digital
I
Check the Key Digital
HD Leeza Users Manual at: www.keydigital.com under
Literature>User Manuals>HD Leeza
The Experts in Digital Video Technology and Solutions.
Model KD-HD1080P
Video Processor
®
HD Leeza Hotline at: 866-439-8988 or 203-798-7187
®
®
HD Leeza expert at: samuel@keydigital.com
®
web site for the latest version of the complete
The Experts in Digital Video Technology and Solutions.
The Experts in Digital Video Technology and Solutions.
Page 1 of 15

Advertisement

loading
Need help?

Need help?

Do you have a question about the HD Leeza KD-HD1080P and is the answer not in the manual?

Questions and answers

Summary of Contents for Key Digital HD Leeza KD-HD1080P

  • Page 1: Quick Setup Guide

    Key Digital Video Processor ® Quick Setup Guide Have a question or a technical issue with your HD Leeza set-up? Call the Key Digital HD Leeza Hotline at: 866-439-8988 or 203-798-7187 ® E-mail the Key Digital ® HD Leeza expert at: samuel@keydigital.com Check the Key Digital ®...
  • Page 2 HD Leeza Quick Setup Guide HD LEEZA (HDL) QUICK SET-UP 1. CONNECT TO AC POWER WITH SUPPLIED CORD DVI-D / HDCP Component (YPbPr) SETTING UP YOUR KEY DIGITAL ® HD LEEZA (HDL) or HDMI or RGBHV (VGA) Pb = B...
  • Page 3 Page 4 of 15 Page 5 of 15 HD Leeza Quick Setup Guide HD Leeza Quick Setup Guide STEP 3: BRING UP HD LEEZA’S ON-SCREEN DISPLAY 3.1.2 Next: HDL is Output is pre-set at the factory to a format setting of “720 x 480p” (OSD), AND CONFIGURE HD LEEZA TO MATCH Your display may prefer some other format, like “1280 x 720p”...
  • Page 4 Page 6 of 15 Page 7 of 15 HD Leeza Quick Setup Guide HD Leeza Quick Setup Guide Bring up HD Leeza’s (HDL’s) On-screen Display (OSD) by pressing and releasing STEP 4: ADJUST HD LEEZA’S VIDEO PROCESSING the Menu Button. The Menu Navigation is achieved by using the Four Navigation SETTINGS TO YOUR INDIVIDUAL PREFERENCES.
  • Page 5 Page 8 of 15 Page 9 of 15 HD Leeza Quick Setup Guide HD Leeza Quick Setup Guide Set HDL Input Aspect Ratio to 1.78 (other Output Aspect Ratios can be used for Now that the resolution has been set and your video has been “Framed” on your special applications).
  • Page 6 Page 10 of 15 Page 11 of 15 HD Leeza Quick Setup Guide HD Leeza Quick Setup Guide HANDY LIST OF HD LEEZA IR REMOTE “HOT” BUTTONS Pressing one button on HD Leeza’s IR Remote performs the following functions Single digit Direct Access Input Switch: R1 - Inhibit OSD Hot Button: The input can be switched as usual using (R6, #) as well as new Single key #.
  • Page 7 The Table presented below is a “living document” based on actual user-experience with & Model # from used by Rate Non-default Non-default HD Leeza and various types of displays. Please be sure to check the Key Digital web Technology HD Leeza HD Leeza (Hz) Settings Settings site www.keydigital.com, or contact tech@keydigital.com...
  • Page 8: Setup Notes

    HD Leeza HD Leeza (Hz) Settings Settings HD Leeza Key Digital Video Processor ® The Experts in Digital Video Technology and Solutions. The Experts in Digital Video Technology and Solutions. The Experts in Digital Video Technology and Solutions. The Experts in Digital Video Technology and Solutions.
  • Page 9 HD Leeza Quick Setup Guide The Experts in Digital Video Technology and Solutions. Key Digital , led by digital video pioneer Mike Tsinberg, ™ develops and manufactures high quality, cutting-edge technology solutions for virtually all applications where high quality video imaging is important. Our products are used by professional broadcasters, corporations, custom installers, home theater retailers, and consumers.
