KD-VP1250
Digital Video Processor, Switcher,
Operating Instructions
KD-VP1250
Key Digital's KD-VP1250 and KD-VP750 are highly-flexible Universal Video Centers with
video processing and video switching abilities. These Hot Rod Series
are capable of scaling, de-interlacing, up-converting, and down-converting virtually any input
source and output to virtually any Standard and High Definition display up to 1080p.
and Universal Video Center
Video Processors
™
Advertisement
Table of Contents
Related Manuals for Key Digital KD-VP1250
Summary of Contents for Key Digital KD-VP1250
-
Page 1: Operating Instructions
Digital Video Processor, Switcher, and Universal Video Center Operating Instructions KD-VP1250 Key Digital’s KD-VP1250 and KD-VP750 are highly-flexible Universal Video Centers with video processing and video switching abilities. These Hot Rod Series Video Processors ™ are capable of scaling, de-interlacing, up-converting, and down-converting virtually any input... -
Page 2: Table Of Contents
............Please read all instructions to insure safe operation of the product. © 2010 Key Digital, Inc. All rights reserved. -
Page 3: About Kd-Vp1250
Page 1 KD-VP1250 About KD-VP1250 Description Digital Video Processor, Switcher, and Distribution Center capable of scaling HDMI, » Component, VGA, Composite, and S-Video source to HDMI, Component, or VGA output. Key Features VGA Inputs and Outputs accommodate Component Video format with supplied breakout »... -
Page 4: Connections, Leds And Button Map
Page 2 Connections, LEDs and Button Map Front LED Lights Output Resolution LEDs Indicate current Output Resolution selected IR Eye Buttons Menu / Left Button Up Button Down Button Select / Right Button Output Resolution Button Enter Menu, Go Back, Navigate Up Navigate Down Choose, go Forward, or... -
Page 5: On Screen Display (Osd) Map
Press the Up or Down Buttons to cycle through Off, 20%, 15%, 10%, or 5% Over Scanning » Quick Setup Guide Begin with the KD-VP1250 and all input/output devices turned off with power cables removed Connect video sources to appropriate input ports on the KD-VP1250 Connect all video outputs to displays or receiving devices... -
Page 6: Rs-232 Commands And Protocol
® ™ ™ ® ® ® Connect your Control System’s Master Controller to the KD-VP1250 unit using the RS-232 port. ½ Follow all instructions provided with your control system. RS-232 Protocol: » Baud Rate = 19600 bits per second »... -
Page 7: Specifications
Page 5 System Control Setup Commands SP C FB E/D/T Front Panel Buttons E = Enable, D = Disable, T = Toggle Enabled/Disabled/ Toggle SP C DF Reset to Factory Defaults Status Commands ST A Out Global System Status Specifications Technical: Inputs: 1x HDMI (DVI-D) on 19-pin HDMI female connector;... -
Page 8: Kd-Vp1250/750 Remote Control
If you still don’t see any picture after changing resolution, press R1 button on the remote to change analog output mode to YPbPr. This is required because if the KD-VP1250/750 is set to RGBHV output, component sync is not available on the output, resulting in the display not... -
Page 9: Safety Instructions
Damage to the power supply or power plug » Exposure to rain or moisture » You MUST use the Power Supply provided with your unit or you VOID the Key Digital Warranty and risk damage to your unit and associated equipment. ®... -
Page 10: How To Contact Key Digital
For marketing and public relations information, please contact us at: Phone: 914-667-9700 ½ E-mail: marketing@keydigital.com ½ Repairs and Warranty Service Should your product require warranty service or repair, please obtain a Key Digital Return Material ® Authorization (RMA) number by contacting us at: Phone: 914-667-9700 ½... - Page 11 , led by digital video pioneer Mike Tsinberg, ® develops and manufactures high quality, cutting-edge technology solutions for virtually all applications where high quality video imaging is important. Key Digital ® is at the forefront of the video industry for Home Theater Retailers, Custom Installers, System Integrators, Broadcasters, Manufacturers, and Consumers.
