Input and Output Features

A list of all of the interfaces to your KD-VPHD2 and their specifications are conveniently
provided in the following able.
Q u a n t i t y x T y p e
2 x H D M I
3 x C o m p o n e n t
V i d e o I n p u t s
3 x Composite
2 x S-Video
1 x HDMI
1 x C o m p o n e n t
V i d e o O u t p u t s
H/V Sync
4 x LR Analog Audio
Audio Inputs
4 x Coaxial Audio
2 x Optical Audio
1 x LR Analog Audio
Audio Outputs
1 x Coaxial Audio
1 x Optical Audio
Service Port
1 x RS232C
Front Buttons
F r o n t a n d R e a r
2 x I R S e n s o r s
I R s e n s o r
1 x 3 . 5 " P h o n o J a c k
R e m o t e I R
2 x 1 0 C h a r a c t e r T y p e
F r o n t L C D
1 x A C - D C A d a p t e r
P o w e r
C o n n e c t o r R e s o l u t i o n s S u p p o r t e d
1920 x 1080i at 60/50 Hz
H D M I
1280 x 720p at 60/50 Hz
720 x 480p & 480i at 60 Hz
R C A J a c k s
720 x 576p & 576i at 50 Hz
720 x 480i at 60 Hz
RCA Jacks
720 x 576i at 50 Hz
720 x 480i at 60 Hz
S-Video
720 x 576i at 50 Hz
1920 x 1080p & 1080i at 60/50 Hz
HDMI
1920 x 540p at 60/50 Hz
1400 x 1050p at 60/50 Hz
1366 & 1280 x 768p at 60/50 Hz
R C A J a c k
1280 x 720p at 60/50 Hz
720 & 640 x 480p at 60 Hz
720 x 576p at 50 Hz
720 x 480i at 60 Hz
RCA Jacks 720 x 576i at 50 Hz
Positive or Negative Sync
Two Channel Stereo
RCA Jacks
RCA Jacks SPDIF (IE60958)
Toslink SPDIF (IE60958)
RCA Jacks Two Channel Stereo
RCA Jacks
SPDIF (IE60958)
Toslink SPDIF (IE60958)
Home Theater Control
System
DSUB-9 Female
Debugging and Firmware
Upgrading
Power/Menu/Up/Down/Left/
8 Buttons
Right input selects

Getting Started

Follow these instructions to quickly connect and configure your KD-VPHD2.
Open the package and you will find the following contents
1. One (1) KD-VPHD2 Digital Video Processor - Video/Audio Switcher Unit
2. External 6-Volt power supply
3. IR Remote Control with batteries included
4. One (1) Alignment Tool*
5. This Operating Instruction Manual
6. Quick Reference Guide
7 . Warranty Card
*Adjustment tool used to set the brightness of the
LCD Display on the KD-VPHD2
Once you have unpacked your new KD-VPHD2 and situated it in its final location you are
ready to begin
You may have source devices with HDMI and/or other various analog sources that you may
wish to ultimately connect to your display and audio system. The KD-VPHD2 comes equipped
with a rich array of video and audio inputs, allowing both flexibility and the means for an all-
digital interface to your existing equipment.
Typical KD-VPHD2 interface configurations for the input (source) devices and the output (sink)
display and/or audio components of your home theater set up are illustrated in the following
Application Example.
CAUTION: Always test first, before permanently
installing the KD-VPHD2
Use extreme care when
:
Interfacing with HDMI and/or DVI-D: always test before permanently
■
installing cables.
Adapting DVI-D to HDMI and HDMI to DVI-D: always use an adapter
■
at the source and test before permanently installing cables.
Restrict your cable lengths as follows:
50-foot maximum HDMI cables driven from a DVI-D source,
■
or less for 1080p video resolution.
30-foot maximum DVI-D cables driven from an HDMI source.
■
