KD-VPHD2 User Manual

Table of Contents

Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
About the KD-VPHD2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Input and Output Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Basic Operation of the KD-VPHD2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
IR Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Control Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
A/V Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Firmware Upgrades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
List of RS232C Commands for KD-VPHD2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Video Processing Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
How to Contact Key Digital ™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Key Features
KD-VPHD2 is a full featured digital video processor and video switcher capable of driving
displays with all popular HD and SD resolutions at 60 Hz and 50 Hz up to and including 1080p.
With the KD-VPHD2 it is possible to connect all of your video sources to your display, and your
audio sources to your audio surround processor. For each input, you can control a broad
range of functions, from Brightness and Contrast, to Size, Position and even Zoom/Aspect
Ratio adjustments. Test patterns built into the KD-VPHD2 are conveniently provided to help you
set up your video system.
Connect and Select any Digital or Analog Video Input
HDMI Digital Video inputs
■
➾
2 HDMI: plug and play and also supports audio
➾
Supports HDCP Copy Protection
➾
To support DVI-D Video, use Key Digital
Analog Video (individual analog video connectors for each of the following interfaces):
■
➾
3 Component: YPbPr
➾
2 S-Video: NTSC, PAL
➾
3 Composite Video: NTSC, PAL
Audio Inputs and Outputs Supported
4 Digital PCM (Coax)
■
2 Toslink (Optical)
■
4 Channel Stereo Analog
■
Processes and Scales any HDMI or Analog Video Input to Match the Native Resolution
of Chosen Display
Uses renowned Key Digital ™ Clear Matrix Pro
■
Supports popular source formats and resolutions
■
Sizes most popular video source formats to precisely match the native resolution of your
■
display including 1080p
Built in test patterns
■
Page 5 of 31
KD-VPHD2 User Manual
™ HDMI to DVI-D adapters and cables
™ and SDS ™ (Super Digital Scaling) Technology
