Key Digital KD-HD1080P Specifications

Video/Audio Processors
KD-HD1080P
KD-HD100P is a Digital Video Processor, Video Switcher and Universal "Distribution Center" with
scaling and deinterlacing capability for up to 2 Composite, 2 S-Video, 2 Component, 1 RGBHV,
2 DVID/HDMI/HDCP and 1 SDI sources/inputs. KD-HD100P outputs up to 100p resolution
using either its Component/RGBHV Video or DVID/HDMI/HDCP outputs.
Key Benefits
4
Universal "Distribution Center" for any DVID/HDMI/HDCP or
Component/RGBHV equipped display including flat panels
or projectors
4
Up-converts (480i, 480p, 720p, 1080i) resolutions of analog
and digital video inputs to a single DVID/HDMI/HDCP or a
single Component Video output up to 1080p resolution
4
Individual customization for any video input for all key video
parameters: Unlimited Aspect Ratio, Brightness, Contrast,
Hue, Edge Enhancement, Saturation, Image Position and all
ISF calibration adjustments
Key Solutions
Integrates any analog and digital source, having different formats, into one format
›
Is a distribution center integrating, processing, deinterlacing, scaling and switching for up to
›
2 Composite, 2 S-Video, 2 Component, 1 RGBHV, 1 SDI-SD and 2 DVID/HDMI/HDCP inputs
into one DVID/HDMI/HDCP output or one component video output
Allows you to customize each input to its best video setting and memorize that setting on
›
each input with a choice of 25 native resolutions, 5 refresh rates and more than 100 output
scanning formats
Provides a one cable solution to the display
›
Will give you the best possible picture quality from your display
›
Supports 3rd party control systems via RS232 and IR
›
12
HD Leeza
4
Accommodates a wide variety of digital and analog video
input/output formats and connectors, including Composite,
S-Video, Component/RGBHV and DVID/HDMI/HDCP
4
HD Leeza's digital video processor with deinterlacing and
scaling is the best way to match interlaced and progressive
scan video from DVD player, Satellite Box, HD DVR, Cable
Box, HDTV Set Top Box, Video Camera, VCR, Computer,
Game Console to the native resolution of your display
4
Incorporates 11 Key Digital Exclusive Technologies
™
4
IR remote with "hot buttons" , RS 232, On Screen Display
General Info
Power: 100VAC to 240VAC,
›
50Hz and 60Hz, NTSC, PAL
Rack Mount: Yes - 2U
›
Remote Control: Included
›
Enclosure Type: Metal
›
Dimensions:
›
17 .5" x 10" x 3.5"
Shipping Carton Dimensions:
›
23" x 13" x 6"
Product Weight: 14 lbs
›
Shipping Weight: 18 lbs
›
™
Commercial Theater Application
Model: KD-HD100P
Optical IR
Satellite Box
Cable Box
DVD Player
DVR Player
VCR
Key Digital Exclusive Technologies
®
g
a l o
A n
1
n e
Z o
D i g
i t a
Z o
l
n e
1
Projector
Wired Remote
RS232 Control
KD-HD1080P
*To connect HDMI Video use
DVI < > HDMI adapter cables
Supported Technologies
Plasma
Game Console
DV Cam
Computer
