KD-CSW4x1 Operating Instructions
Important Safety Instructions.
Please be sure to follow these instructions for safe operation of your unit
1.
Read these instructions.
2.
Keep these instructions.
3.
Heed all warnings.
4.
Follow all instructions.
5.
Do not use this apparatus near water.
6.
Clean only with dry cloth.
7.
Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.
8.
Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10.
Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11.
Only use attachments/accessories specified by the manufacturer.
12.
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13.
Unplug this apparatus during lightning storms or when unused for long periods of time.
14.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been dropped.
WARNING – To reduce the risk of fire or electric shock, do not expose his
apparatus to rain or moisture.
Apparatus shall not be exposed to dripping or splashing and no objects
filled with liquids, such as vases, shall be placed on the apparatus.
© 2006 Key Digital, Inc. All rights reserved.
Introduction
Key Digital
FlashMax Series
KD-CSW4x1 is a versatile multi-input audio/video switcher for
®
™
connecting video and audio sources to a TV video display or monitor. It is the ideal solution
when your TV, monitor, or receiver does not have enough video and audio inputs. It features 4
independent component video/audio inputs with one component video/audio output. Digital audio
(PCM)or analog audio (L & R) can also be switched through the KD-CSW4x1. All input selections
are clearly displayed on the front panel with blue LED indicators.
Home Theater Application
Model: KD-CSW4x1
Optical IR
Cable Box
DVD Player
Satellite Box
KD-CSW4x1 Operating Instructions
Projector
Surround Sound
RS232 Control
KD-CSW4x1
*All Component
sources can be
Game Console
substituted with
RGBHV sources
Page 1
