Video/Audio Switchers
KD-CSW4x1
KD-CSWx1 is a Video/Audio Switcher with capability of switching up to
 Component/RGBHV Sources/Inputs to 1 output

Key Benefits

4
Flexible switching of up to 4 YPrPb/RGBHV Video/Audio
sources (Component, RGBHV, S-Video, Composite) with
Coaxial/Digital (PCM) Audio
4
Switches Left, Right analog stereo,
Coaxial/Digital (PCM) Audio

Key Solutions

Provides seamless switching from 4 analog sources to 1 output
Allows for multiple expansions of YPrPb/RGBHV sources/inputs to your display
Supports 3rd party control systems via RS232 and IR
2
4
Front LEDs indicate the selected source and
input/output status
4
Incorporates 4 Key Digital
Exclusive Technologies
4
Optical IR, Front Panel Controls, RCA connectors

General Info

Power: 100VAC to 240VAC,
50Hz and 60Hz, NTSC, PAL
Rack Mount: Yes - 1U
Remote Control: Included
Enclosure Type: Metal
Dimensions:
17 .25" x 4.5" x 1.75"
Shipping Carton Dimensions:
23.5" x 7" x 4.5"
Product Weight: 4 lbs
Shipping Weight: 6 lbs
Home Theater Application
Model: KD-CSWx1
Optical IR
Cable Box
DVD Player
Satellite Box
Key Digital
Exclusive Technologies
®
Projector
Surround Sound
RS232 Control
KD-CSW4x1
*All Component
sources can be
Game Console
substituted with
RGBHV sources
Supported Technologies
2
