ionmax Rhine ION650 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

9/9/22, 2:54 PM
Ionmax Rhine user manual
v1.0. Updated August 2022.
Please read the user manual to ensure safe and proper usage.
Please read the instructions carefully before using and be sure to keep the user
manual where it is easily accessible for future reference.
PLEASE NOTE:
https://ionmax.com.au/blogs/manuals/ionmax-rhine
Ionmax Rhine user manual

Table of contents

1/27

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rhine ION650 and is the answer not in the manual?

Questions and answers

Related Manuals for ionmax Rhine ION650

Summary of Contents for ionmax Rhine ION650

  • Page 1: Table Of Contents

    9/9/22, 2:54 PM Ionmax Rhine user manual Ionmax Rhine user manual v1.0. Updated August 2022. Please read the user manual to ensure safe and proper usage. Please read the instructions carefully before using and be sure to keep the user manual where it is easily accessible for future reference.

  • Page 2: Important Safety Instructions

    9/9/22, 2:54 PM Ionmax Rhine user manual The user manual may be altered at any time to assist in quality improvement. The design and product development may be upgraded without public notice. This unit uses a flammable refrigerant. If the refrigerant leaks and comes in contact with fire or heating parts, it will create harmful gas and there is a risk of fire.

  • Page 3: Operational Precautions

    9/9/22, 2:54 PM Ionmax Rhine user manual This unit uses a flammable refrigerant. If the refrigerant leaks and comes in contact with fire or heating parts, it will create harmful gas and there is a risk of fire. The unit is designed only for use with R290 (propane) gas as the designated refrigerant.
  • Page 4 9/9/22, 2:54 PM Ionmax Rhine user manual Do not tip the unit to any side as spilled water may damage the unit. Ensure that the drainpipe is placed downwards after installation so that the water can be continuously discharged. Never immerse the unit in water or other liquids, or touch the unit with wet hands.

  • Page 5: Features

    Maintenance and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of a person competent in the use of flammable refrigerants. For the service manual or further assistance, please contact Ionmax. Features Compressor dehumidifier - suitable for warm climates Environmentally friendly - uses eco-friendly R290 refrigerant Moisture removal - 50 litres/day (30°C RH80%)

  • Page 6: Specifications

    Washable pre-filter - removes large particles such as dust and hair from dehumidified Continuous drainage option - drainage hose provided WiFi app control - remote monitoring and settings via mobile app Specifications Model: Ionmax Rhine ION650 Voltage: AC 220V 50Hz Power consumption: 793W Net weight: 19kg...
  • Page 7 9/9/22, 2:54 PM Ionmax Rhine user manual 1. Place the unit in an upright position on a stable, level surface. Please ensure the unit is not sitting on its own cable. 2. Only use the unit in areas larger than 7 square meters.
  • Page 8 9/9/22, 2:54 PM Ionmax Rhine user manual under direct sunlight areas where oil or water may be splashed mechanical vibrations or shock excessive dust uneven surface   Product Description Control Panel https://ionmax.com.au/blogs/manuals/ionmax-rhine 8/27...

  • Page 9: Operating Instructions

    9/9/22, 2:54 PM Ionmax Rhine user manual Operating Instructions ℹ There is a protective 3-minute time delay on the compressor. Please allow 3 minutes for the unit to resume the dehumidification process. Power button Connect the power plug to an appropriate electrical outlet. The digital display will show the ambient relative humidity (RH) level.
  • Page 10 9/9/22, 2:54 PM Ionmax Rhine user manual Note: If the unit has been switched off and on again, it will resume operation in the same mode selected from its last use. Mode button Press the Mode button to choose between different modes. The corresponding mode’s...
  • Page 11 9/9/22, 2:54 PM Ionmax Rhine user manual Digital Display The digital display shows the current relative humidity (RH) level by default at all times. To view the room’s ambient temperature on the digital display, hold down the Increase button. While in Timer setting mode, the digital display will show the number of hours selected.
  • Page 12 9/9/22, 2:54 PM Ionmax Rhine user manual RH indicated has a +/- 10% RH tolerance and may vary depending on the room temperature. While in operation, the unit will begin dehumidifying the air if the room’s relative humidity (RH) level is 3% higher than the selected RH level.
  • Page 13 9/9/22, 2:54 PM Ionmax Rhine user manual Low fan speed   High fan speed Note: Fan Speed toggling is disabled during Laundry mode. Timer button Press the Timer button to enter Timer setting mode. Use the Increase and Decrease buttons to set a timer from 1 to 24 hours, or “00” to cancel the timer function (the Timer indicator light will switch off).
  • Page 14 10 minutes. 6. The selected mode will be flashing during the defrosting process.   Mobile App Setup Download the Ionmax app on your phone. Scan the QR code or visit ionmax.com.au/app   1. Register a new account on your phone, or log in to your existing account for the Ionmax app.
  • Page 15 5. Follow the prompts on the app to finish the Bluetooth connection. 2. Method 2: Add Manually 1. On your Ionmax app, select or create a new location for your dehumidifier . 2. Select “Devices” and click on “+” to add a new device.
  • Page 16 9/9/22, 2:54 PM Ionmax Rhine user manual          https://ionmax.com.au/blogs/manuals/ionmax-rhine 16/27...
  • Page 17 9/9/22, 2:54 PM Ionmax Rhine user manual   Emptying the Water Tank 1. When the water tank is full, the Full Tank indicator will blink and the unit will beep and stop operating.   2. Do not move the unit or remove the...
  • Page 18 9/9/22, 2:54 PM Ionmax Rhine user manual 1. To remove the water tank, grip the handles of the water tank and carefully pull it out. 2. Discard the water from the tank. 3. Clean the water tank and reinstall it back into the unit. The Full Tank indicator light will switch off and the unit can resume normal operation.

  • Page 19: Maintenance

    9/9/22, 2:54 PM Ionmax Rhine user manual The hose must lead to an appropriate drain Pull the drainage outlet’s protective cover at a downward slope with no sharp bends. aside and insert one end of the drainage hose into the outlet.
  • Page 20 9/9/22, 2:54 PM Ionmax Rhine user manual 2. Clean the outer casing of the unit using a soft damp cloth with warm water and mild detergent. Do not use solvents or abrasive materials. 3. Dry thoroughly with a soft dry cloth after cleaning.
  • Page 21 9/9/22, 2:54 PM Ionmax Rhine user manual 1. Switch off the unit, wait for the fan to stop, then unplug the power cord from the electrical outlet. Remove the filter located at the back of the unit. 2. Clean the filter gently using a vacuum cleaner with a soft brush, or by rinsing with water.

  • Page 22: Troubleshooting

    9/9/22, 2:54 PM Ionmax Rhine user manual Troubleshooting The following conditions are normal: The compressor will stop or rest for 3 minutes every time the unit shuts down or is plugged into the electrical outlet. This helps ensure a smooth start for the dehumidifier.
  • Page 23 9/9/22, 2:54 PM Ionmax Rhine user manual Problem Possible cause Solution The ambient temperature is too This is normal if the temperature is low The ambient Do not use the unit in small and closed spaces temperature is too where heat may accumulate. Move the unit to a...
  • Page 24 Allow a few minutes for the compressor to settle compressor delayed down before it is switched on is not running Compressor is Contact Ionmax support and do not attempt to fix faulty this as it may cause injury Error codes Error Possible Cause Solution...

  • Page 25: Warranty Details

    30 seconds. 20% RH Please contact Ionmax support if any problem persists. Do not try to repair the unit yourself, as this could cause an electrical shock and void your warranty. Warranty Details Congratulations on your purchase! It is our aim to provide you with quality products that you can trust.

  • Page 26: Warranty Registration

    Any damage caused by improper power input or improper cable connection. Warranty Registration my.andatech.com.au Register your Ionmax Rhine online at or fill out this form and forward it to the address below with a copy of your proof of purchase. Contact us at 1300 800 200 or visit ionmax.com.au...
  • Page 27 9/9/22, 2:54 PM Ionmax Rhine user manual Andatech Pty Ltd PO Box 3038, Nunawading VIC 3131, Australia. Phone: 1300 800 200   Fax: 1300 883 802   Email: support@andatech.com.au Date of Purchase Place of Purchase Serial No. Surname Given Name...
