9/9/22, 2:58 PM
Ionmax Leone user manual
v1.0. Updated August 2022.
Please read the user manual to ensure safe and proper usage.
Please read the instructions carefully before using and be sure to keep the user
manual where it is easily accessible for future reference.
PLEASE NOTE:
https://ionmax.com.au/blogs/manuals/ionmax-leone
Ionmax Leone user manual

Table of contents

1/28

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Leone ION625 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ionmax Leone ION625

Summary of Contents for ionmax Leone ION625

  • Page 1: Table Of Contents

    9/9/22, 2:58 PM Ionmax Leone user manual Ionmax Leone user manual v1.0. Updated August 2022. Please read the user manual to ensure safe and proper usage. Please read the instructions carefully before using and be sure to keep the user manual where it is easily accessible for future reference.

  • Page 2: Important Safety Instructions

    9/9/22, 2:58 PM Ionmax Leone user manual The user manual may be altered at any time to assist in quality improvement. The design and product development may be upgraded without public notice. This unit uses a flammable refrigerant. If the refrigerant leaks and comes in contact with fire or heating parts, it will create harmful gas and there is a risk of fire.

  • Page 3: Operational Precautions

    9/9/22, 2:58 PM Ionmax Leone user manual This unit uses a flammable refrigerant. If the refrigerant leaks and comes in contact with fire or heating parts, it will create harmful gas and there is a risk of fire. The unit is designed only for use with R290 (propane) gas as the designated refrigerant.
  • Page 4 9/9/22, 2:58 PM Ionmax Leone user manual Do not tip the unit to any side as spilled water may damage the unit. Ensure that the drainpipe is placed downwards after installation so that the water can be continuously discharged. Never immerse the unit in water or other liquids, or touch the unit with wet hands.

  • Page 5: Features

    Maintenance and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of a person competent in the use of flammable refrigerants. For the service manual or further assistance, please contact Ionmax. Features Compressor dehumidifier - suitable for warm climates Environmentally friendly - uses eco-friendly R290 refrigerant Moisture removal - 25 litres/day (30°C RH80%)

  • Page 6: Specifications

    Washable pre-filter - removes large particles such as dust and hair from dehumidified Continuous drainage option - drainage hose provided WiFi app control - remote monitoring and settings via mobile app Specifications Model: Ionmax Leone ION625 Voltage: 220-240V ~ 50Hz Power consumption: 395W Net weight: 14.5kg...
  • Page 7 9/9/22, 2:58 PM Ionmax Leone user manual https://ionmax.com.au/blogs/manuals/ionmax-leone 7/28...
  • Page 8 9/9/22, 2:58 PM Ionmax Leone user manual 1. Place the unit in an upright position on a stable, level surface. Please ensure the unit is not sitting on its own cable. 2. Only use the unit in areas larger than 4 square meters.
  • Page 9 9/9/22, 2:58 PM Ionmax Leone user manual 3-Colour Humidity Indicator The colour indicator on the front of the unit indicates the room’s relative humidity level, as indicated above.   Control Panel https://ionmax.com.au/blogs/manuals/ionmax-leone 9/28...

  • Page 10: Operating Instructions

    9/9/22, 2:58 PM Ionmax Leone user manual Operating Instructions ℹ There is a protective 3-minute time delay on the compressor. Please allow 3 minutes for the unit to resume the dehumidification process. Stand-By / Power Button Connect the power plug to an appropriate electrical outlet. The POWER indicator will light up to indicate the unit is in stand-by mode.
  • Page 11 9/9/22, 2:58 PM Ionmax Leone user manual and the compressor will stop immediately, while the fan will shut down after 30 seconds. Note: If the unit has been switched off and on again, it will resume operation in the same mode selected from its last use.
  • Page 12 9/9/22, 2:58 PM Ionmax Leone user manual The digital display shows the current relative humidity (RH) level by default at all times. To view the room’s ambient temperature on the digital display, hold down the Increase button. While in Timer setting mode, the digital display will show the number of hours selected.
  • Page 13 9/9/22, 2:58 PM Ionmax Leone user manual Timer button Press the Timer button to enter Timer setting mode. Use the Increase and Decrease buttons to set a timer from 1 to 12 hours, or “00” to cancel the timer function (the Timer indicator light will switch off).
  • Page 14 9/9/22, 2:58 PM Ionmax Leone user manual Note: While the unit is operating, hold down the Increase button to view the room’s ambient temperature on the digital display. Decrease button Press the Decrease button to decrease the timer (during Timer setting mode) or to decrease the desired humidity level.
  • Page 15 9/9/22, 2:58 PM Ionmax Leone user manual Press the Sleep / Reset button to deactivate Sleep mode. The Sleep mode indicator light will switch off. If the Filter Reset indicator lights up, clean the filters according to the Filter Maintenance instructions.
  • Page 16 5. Follow the prompts on the app to finish the Bluetooth connection. 2. Method 2: Add Manually 1. On your Ionmax app, select or create a new location for your dehumidifier . 2. Select “Devices” and click on “+” to add a new device.
  • Page 17 9/9/22, 2:58 PM Ionmax Leone user manual 4. Enter your WiFi network SSID and password on the app. *Please use a 2.4GHz network only. 5. Confirm that the WiFi indicator on the device is blinking and click ‘Next’. 6. The app will search for the dehumidifier and prompt for connection automatically.
  • Page 18 9/9/22, 2:58 PM Ionmax Leone user manual          https://ionmax.com.au/blogs/manuals/ionmax-leone 18/28...
  • Page 19 9/9/22, 2:58 PM Ionmax Leone user manual   Emptying the Water Tank 1. When the water tank is full, the Full Tank indicator will blink and the unit will beep �� and stop operating. 2. Do not move the unit or remove the water tank if the unit is still operating as water may leak, damage the unit, or cause an electric shock.

  • Page 20: Maintenance

    9/9/22, 2:58 PM Ionmax Leone user manual Full Tank indicator light will blink and the unit will not operate if �� the water tank is not positioned correctly.    Continuous Drainage Option The unit comes with a hose that can be connected for continuous drainage. This removes the need to empty the water tank periodically.
  • Page 21 9/9/22, 2:58 PM Ionmax Leone user manual 3. Dry thoroughly with a soft dry cloth after cleaning. 4. In order to avoid damage, do not wash the machine with water or let water drip into the air inlet or outlet.

  • Page 22: Troubleshooting

    9/9/22, 2:58 PM Ionmax Leone user manual Caution: Never run the unit without the filter. Dust build-up in the unit can cause ❗ malfunction and overheating. Before storing 1. Switch off the unit, wait for the fan to stop, and then unplug the power cord from the electrical outlet.
  • Page 23 9/9/22, 2:58 PM Ionmax Leone user manual If your dehumidifier is not operating as expected, please check the following solutions first:   Problem Possible cause Solution The unit is Make sure the power plug is pushed completely unplugged into the electrical outlet and switched on...
  • Page 24 9/9/22, 2:58 PM Ionmax Leone user manual Problem Possible cause Solution Ensure nothing is obstructing the unit’s air inlets The air inlet or and outlets and that the unit is set up correctly outlet is blocked according to the Unit Setup guide...

  • Page 25: Warranty Details

    90%RH operating and the fan will keep running. Please contact Ionmax support if any problem persists. Do not try to repair the unit yourself, as this could cause an electrical shock and void your warranty. Warranty Details https://ionmax.com.au/blogs/manuals/ionmax-leone...
  • Page 26 9/9/22, 2:58 PM Ionmax Leone user manual Congratulations on your purchase! It is our aim to provide you with quality products that you can trust. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage.

  • Page 27: Warranty Registration

    Any damage caused by improper power input or improper cable connection. Warranty Registration my.andatech.com.au Register your Ionmax Leone online at or fill out this form and forward it to the address below with a copy of your proof of purchase. Contact us at 1300 800 200 or visit ionmax.com.au...
  • Page 28 9/9/22, 2:58 PM Ionmax Leone user manual Date of Purchase Given Name Address Suburb Postcode State Contact No. Email https://ionmax.com.au/blogs/manuals/ionmax-leone 28/28...
