L-Desk
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-38
Français pg 39-43
Español pg 44-48

Advertisement

loading

Related Manuals for abc L-Desk

Summary of Contents for abc L-Desk

  • Page 1 L-Desk NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. English pg 1-38 Français pg 39-43 Español pg 44-48...
  • Page 2 Table of Contents Assembly Tools Required Part Identification No. 2 Phillips Screwdriver Hardware Identification Tip Shown Actual Size Hardware Usage Guide Assembly Steps 6-38 Hammer Not actual size Français 39-43 Español 44-48 Safety 49-50 Warranty Page 2...
  • Page 3 Now you know Part Identification our ABCs. å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help distinguish similar parts from each other. Use this part identification to help identify similar parts. END (1) SHELF/BOTTOM (2) LONG TOP MOLDING (1)
  • Page 4 Hardware Identification å Screws are shown actual size. You may receive extra hardware with your unit. (EXTENSION SET SHOWN SEPARATED) EXTENSION EXTENSION 10A SLIDE CAM - 2 4B FILE GLIDE - 2 35MA 35MC RAIL - 2 SLIDE - 2 HIDDEN WOOD MOLDING...
  • Page 5 Hardware Usage Guide HOW TO USE A HIDDEN CAM & CAM DOWEL Insert the metal end of the CAM DOWEL into the HIDDEN CAM. Cam Dowel Arrow Hole Push a HIDDEN CAM into Metal end the part. The arrow in the HIDDEN CAM must point toward the hole in the edge Hidden Cam...
  • Page 6 Step 1 å Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor. Pro Tip: You will need someone's help later å Push eight HIDDEN CAMS (1F) into the END (A). in assembly.
  • Page 7 Step 2 å Insert two WOOD DOWELS (15F) into the LEGS (Q and R). å Fasten the LEGS (Q and R) to the END (A). Tighten six HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the LEGS insert into the END.
  • Page 8 Step 3 å Push two HIDDEN CAMS (1F) into the long edge of the SMALL MODESTY PANEL (E). å Push two HIDDEN CAMS (1F) into the short edge of the SMALL MODESTY PANEL (E). Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. Do not tighten the HIDDEN CAMS in this step.
  • Page 9 Step 4 å Fasten the SMALL MODESTY PANEL (E) to the END (A). Tighten two HIDDEN CAMS. i t h f a c S u r D E N H I D Page 9...
  • Page 10 Step 5 å Insert four CAM DOWELS (2F) into the DESK TOP (C) exactly as shown with the metal end facing up. å With someone's help, fasten the END (A) and SMALL MODESTY PANEL (E) to the DESK TOP (C). Tighten four HIDDEN CAMS.
  • Page 11 Step 6 å Fasten the PLATES (41G) to the DESK TOP (C) exactly as shown. Use six BLACK 9/16" LARGE HEAD SCREWS (1S). å NOTE: The PLATES will overhang the edge of the TOP. å Push four HIDDEN CAMS (1F) into the DESK TOP (C). BLACK 9/16"...
  • Page 12 Step 7 å Push sixteen HIDDEN CAMS (1F) into the LEFT END (B) and UPRIGHT (D). Arrow Arrow (16 used) Arrow Page 12...
  • Page 13 Step 8 å Separate the EXTENSION SLIDES (35MC) from the EXTENSION RAILS (35MA) as shown in the upper diagram below. Be prepared, the parts are greasy. å Fasten the EXTENSION RAILS (35MA) to the LEFT END (B) and UPRIGHT (D). Use four GOLD 5/16"...
  • Page 14 Step 9 å Turn six CAM SCREWS (8F) into the LEGS (O and Q). Page 14...
  • Page 15 Step 10 å Insert two WOOD DOWELS (15F) into the LEGS (O and Q). å Fasten the LEGS (O and Q) to the UPRIGHT (D). Tighten six HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the LEGS insert into the UPRIGHT.
  • Page 16 Step 11 å Insert two WOOD DOWELS (15F) into the UPRIGHT (D). Don't worry. It isn't å Place the BACK (L) onto the WOOD DOWELS in the UPRIGHT (D). Rome. This can be built in a day. Page 16...
  • Page 17 Step 12 å Push eight HIDDEN CAMS (1F) into the SHELF/BOTTOMS (F). Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. Do not tighten the HIDDEN CAMS in this step. Arrow Metal end Arrow Metal end Page 17...
  • Page 18 Step 13 å Fasten the SHELF/BOTTOMS (F) to the UPRIGHT (D). Tighten four HIDDEN CAMS. S u r f a c i t h H I D D E N Notched edge S u r f a c i t h H I D D E N Page 18...
  • Page 19 Step 14 å NOTE: The BOTTOM MOLDING (H) is wider than the SHELF MOLDING (G). å Slide the SHELF MOLDING* (G) onto the notched edge of the upper SHELF/BOTTOM (F). å Slide the BOTTOM MOLDING* (H) onto the notched edge of the lower SHELF/BOTTOM (F). The groove is closer to å...
  • Page 20 Step 15 å Turn three CAM SCREWS (8F) into one LEFT REAR LEG (R). å Insert one WOOD DOWEL (15F) into the LEFT REAR LEG (R). å Fasten the LEFT END (B) to the LEFT REAR LEG (R). Tighten three HIDDEN CAMS.
  • Page 21 Step 16 å Insert two WOOD DOWELS (15F) into the BACK (L). å Fasten the LEFT END (B) to the SHELF/BOTTOMS (F). Tighten four HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the BACK insert into the END. Page 21...
  • Page 22 Step 17 å Insert four CAM DOWELS (2F) into the DESK TOP (C) exactly as shown with the metal end facing up. å With someone's help, fasten the LEFT END (B) and UPRIGHT (D) to the DESK TOP (C). Tighten four HIDDEN CAMS. å...
  • Page 23 Step 18 å Turn seven CAM SCREWS (8F) into the LEFT FRONT LEG (M) and LONG TOP MOLDING (P). Page 23...
  • Page 24 Step 19 å Tap one MOLDING CONNECTOR (17F) into the notches in the LEFT FRONT LEG (M) and LONG TOP MOLDING (P). Use your hammer to tap the MOLDING CONNECTOR (17F) into the notches in the LEG and MOLDING. Flat end Page 24...
  • Page 25 Step 20 å Insert one WOOD DOWEL (15F) into the LEFT FRONT LEG (M). å Fasten the LEFT FRONT LEG (M) to the LEFT END (B). Tighten three HIDDEN CAMS. å NOTE: Be sure the WOOD DOWEL in the LEG inserts into the END. å...
  • Page 26 Step 21 å Push eight HIDDEN CAMS (1F) into the RETURN END (V). Now might be a å Push two HIDDEN CAMS (1F) into the long edge of the good time to refresh LARGE MODESTY PANEL (T). your drink. å Push two HIDDEN CAMS (1F) into the short edge of the LARGE MODESTY PANEL (T).
  • Page 27 Step 22 å Insert one WOOD DOWEL (15F) into the RETURN END (V). å With someone's help, fasten the LARGE MODESTY PANEL (T) to the RETURN END (V). Tighten two HIDDEN CAMS. å NOTE: Be sure the WOOD DOWEL in the END inserts into the MODESTY PANEL.
  • Page 28 Step 23 å Insert two WOOD DOWELS (15F) into the RETURN TOP (S). å Insert four CAM DOWELS (2F) into the RETURN TOP (S) exactly as shown with the metal end facing up. å With someone's help, fasten the LARGE MODESTY PANEL (T) and RETURN END (V) to the RETURN TOP (S).
  • Page 29 Step 24 å Turn three CAM SCREWS (8F) into one RIGHT REAR LEG (Q). å Insert one WOOD DOWEL (15F) into the RIGHT REAR LEG (Q). å Fasten the RIGHT REAR LEG (Q) to the RETURN END (V). Tighten three HIDDEN CAMS. å...
  • Page 30 Step 25 å Turn six CAM SCREWS (8F) into the RIGHT FRONT LEG (N) and SHORT TOP MOLDING (U). å Tap one MOLDING CONNECTOR (17F) into the notches in the RIGHT FRONT LEG (N) and SHORT TOP MOLDING (U). Use your hammer to tap the MOLDING CONNECTOR (17F) into the notches in the LEG and MOLDING.
  • Page 31 Step 26 å Insert one WOOD DOWEL (15F) into the RIGHT FRONT LEG (N). å Fasten the RIGHT FRONT LEG (N) to the RETURN END (V). Tighten three HIDDEN CAMS. å NOTE: Be sure the WOOD DOWEL in the LEG inserts into the END. å...
  • Page 32 Step 27 å With someone's help, carefully stand the desk assembly upright, and insert two WOOD DOWELS (15F) into the SMALL MODESTY PANEL (E). å With someone's help, carefully stand the return assembly upright, and place the LARGE MODESTY PANEL (T) onto the WOOD DOWELS in the SMALL MODESTY PANEL (E) with the RETURN TOP (S) resting on the PLATES fastened to the DESK TOP (C).
  • Page 33 Step 28 å Fasten the LARGE MODESTY PANEL (T) to the END (A). Use four BROWN 1" FLAT HEAD SCREWS (12S). å NOTE: You should start each SCREW a few turns before completely tightening any of them. å Fasten the LONG TOP MOLDING (P) to the SHORT TOP MOLDING (U).
  • Page 34 Step 29 The tabs should insert freely into the slots. Gently tilt the DRAWER SIDES side to side until the tabs slip into the slots. BROWN 1" FLAT HEAD SCREW (2 used for the MOLDING) Groove å å Fasten the DRAWER FRONT MOLDING (K) to the Insert the DRAWER SIDES (D14 and D15) at an angle DRAWER FRONT (J).
  • Page 35 Step 30 å Insert a SLIDE CAM (10A) into each DRAWER SIDE (D14 and D15). å Fasten the EXTENSION SLIDES (35MC) to the DRAWER SIDES (D14 and D15). Use four GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #3. å...
  • Page 36 Step 31 å Push a FILE GLIDE (4B) onto each DRAWER SIDE (D14 and D15) as shown. Almost time to celebrate! With a nap. Page 36...
  • Page 37 Step 32 å To insert the drawer into your unit, line up the EXTENSION SLIDES on the drawer with the EXTENSION RAILS on the unit and push the drawer into the unit until the drawer is fully inserted. The drawer will push in hard until it is all the way in, then it will slide in and out easier.
  • Page 38 Step 33 å To make adjustments to the drawer, loosen SCREW #3 in the SLIDES a 1/4 turn, then turn the cam clockwise or counter-clockwise. Notice how the drawer raises or lowers as you turn the cam. By adjusting the drawer this way, it will help the DRAWER FRONT line up better when closed.
  • Page 39 Bureau en L Utilisez les instructions d’ a ssemblage en français avec les NOUS CONTACTER EN PREMIER schémas étape par étape du manuel d’instruction en anglais. AVANT D'EFFECTUER TOUT RETOUR AU MAGASIN. Chaque étape en français correspond à la même étape en Nous faisons de notre mieux pour nous assurer que votre meuble anglais.
  • Page 40 Guide d'utilisation de la visserie ÉTAPE 3 UTILISATION DE LA EXCENTRIQUE ESCAMOTABLE ET DE LA Ne pas serrer les EXCENTRIQUES ESCAMOTABLES dans CHEVILLE D'EXCENTRIQUE cette étape. 1. Enfoncer un EXCENTRIQUE ESCAMOTABLE dans la partie. La Enfoncer deux EXCENTRIQUES ESCAMOTABLES (1F) dans le flèche dans l’EXCENTRIQUE ESCAMOTABLE doit être dirigée vers bord long du PETIT VOILE DE FOND (E).
  • Page 41 ÉTAPE 8 ÉTAPE 13 Séparer les COULISSES D'EXTENSION (35MC) des GLISSIÈRES Fixer les TABLETTE/DESSOUS (F) au MONTANT (D). Serrer D'EXTENSION (35MA) comme l'indique le schéma du haut quatre EXCENTRIQUES ESCAMOTABLES. ci-dessous. Faire attention car les pièces sont graissées. ÉTAPE 14 Fixer les GLISSIÈRES D'EXTENSION (35MA) à...
  • Page 42 ÉTAPE 18 ÉTAPE 23 Faire tourner sept VIS D'EXCENTRIQUE (8F) dans le PIED AVANT Insérer deux CHEVILLES EN BOIS (15F) dans le DESSUS GAUCHE (M) et la MOULURE DE DESSUS LONG (P). DE RETOUR (S). Insérer quatre CHEVILLES D’EXCENTRIQUE (2F) dans le ÉTAPE 19 DESSUS DE RETOUR (S) exactement comme il l’est indiqué...
  • Page 43 ÉTAPE 27 ÉTAPE 31 Avec l’ a ide d’une autre personne, relever, avec précaution, Enfoncer une ARMATURE POUR DOSSIERS (4B) sur chaque l’ensemble du bureau, et insérer deux CHEVILLES EN BOIS (15F) CÔTÉ DE TIROIR (D14 et D15) comme il l’est indiqué. dans le PETIT VOILE DE FOND (E).
  • Page 44 Escritorio en L Use estas instrucciones de ensamblaje en español junto con las CONTÁCTENOS PRIMERO figuras paso-a-paso provistas en el folleto inglés. Cada paso en ANTES DE HACER DEVOLUCIONES A LA TIENDA. español corresponde al mismo paso en inglés. Compare la “Lista Tratamos de asegurar que su mueble llega en condición excelente.
  • Page 45 Guía de uso de herrajes PASO 3 CÓMO UTILIZAR EL EXCÉNTRICO ESCONDIDO Y No apriete los EXCÉNTRICOS ESCONDIDOS en este paso. EL PASADOR DE EXCÉNTRICO Empuje dos EXCÉNTRICOS ESCONDIDOS (1F) en el borde largo 1. Empuje un EXCÉNTRICO ESCONDIDO dentro de la parte. La del VELO DE FONDO PEQUEÑO (E).
  • Page 46 PASO 8 PASO 13 Separe las CORREDERAS DE EXTENSIÓN (35MC) de los RIELES Fije los ESTANTES/FONDOS (F) al PARAL (D). Apriete cuatro DE EXTENSIÓN (35MA) como se muestra en el diagrama EXCÉNTRICOS ESCONDIDOS. superior más abajo. Prepárese, las piezas son grasientas. PASO 14 Fije los RIELES DE EXTENSIÓN (35MA) al EXTREMO IZQUIERDO (B) y al PARAL (D).
  • Page 47 PASO 18 PASO 23 Atornille siete BIELAS DE EXCÉNTRICO (8F) en la PATA Inserte dos PASADORES DE MADERA (15F) en el PANEL DELANTERA IZQUIERDA (M) y en la MOLDURA DE PANEL SUPERIOR DE MESA AUXILIAR (S). SUPERIOR LARGO (P). Inserte cuatro PASADORES DE EXCÉNTRICO (2F) en el PANEL SUPERIOR DE MESA AUXILIAR (S) exactamente como se PASO 19 muestra con el extremo metálico hacia arriba.
  • Page 48 PASO 27 PASO 30 Con la ayuda de otra persona, cuidadosamente ponga el ensamblaje Inserte un EXCÉNTRICO DE CORREDERA (10A) dentro cada del escritorio en posición vertical, e inserte dos PASADORES DE LADO DE CAJÓN (D14 y D15). MADERA (15F) en el VELO DE FONDO PEQUEÑO (E). Fije las CORREDERAS DE EXTENSIÓN (35MC) a los LADOS DE Con la ayuda de otra persona, cuidadosamente ponga el CAJÓN (D14 y D15).
  • Page 49 WARNING Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Carefully read the following chart. Look out for: What can happen: How to avoid the problem: • Overloaded shelves or drawers. •...
  • Page 50 ADVERTENCIA Por favor use el mobiliario correcta y seguramente. El mal uso puede causar riesgos de seguridad o daño a las unidades o artículos domésticos. Cuidadosamente lea la tabla a continuación. Esté alerto de: Puede ocurrir: Evitar el problema: • Estantes o cajones sobrecargados. •...
  • Page 51 5-YEAR LIMITED WARRANTY 1. We provide limited warranty coverage to the original purchaser of this product for a period of five 4. This Warranty applies only to warranted defects that first arise and years from the date of purchase against defects in materials or workmanship of furniture components. are reported to us within the warranty coverage period.
