Linear Technology DC890B Quick Start Manual page 10

Item Qty
1 3
2 0
3 0
4 1
5 1
6 9
7 1
8 5
9 1
10 15
11 43
12 1
13 5
14 1
15 0
16 1
17 0
18 1
19 3
20 9
21 1
22 2
23 2
24 1
25 0
26 1
27 0
28 1
Downloaded from Elcodis.com electronic components distributor
QUICK START GUIDE FOR DEMONSTRATION CIRCUIT 890B
Reference
C80,C81,C89
C94 (Opt)
C88 (Opt)
C88
C36
C1,C2,C32,C35,C38,C76,C78,
C79,C92
C82
C8,C37,C60,C77,C91
C83
C11,C12,C27-31,C34,C42,C44,
C52,C53,C57,C62,C85
C13-26,C39,C40,C45-50,C54-56,
C58,C59,C61,C63-75,C90,C93
C43
C4,C5,C33,C84,C87
C10
C9 (Opt)
C41
C86 (Opt)
C51
C3,C6,C7
D1-8,D12
D10
D11,D13
D9,D14
J1
J7,J8 (Opt)
J2
J3,J11 (Opt)
J4
Part Description
CAP,TANT,470uF,10V,20%, 7343
CAP,TANT,470uF,10V,20%, 7343
CAP, POLY-TA, 1000uF, 4V
20%,7343
CAP, POLY-TA, 680uF, 4V 20%,
7343
CAP, 330uF16V 20PCT
CAP, X5R 10uF 6.3V 20% 1206
CAP,TANT,4.7uF,10V,20%,3216
CAP, X7R 1uF 10V 10% 0603
CAP, X5R 0.22uF 16V 20% 0603
CAP, X7R 0.1uF 16V 10% 0603
CAP, X5R,0.1uF,10V,10%,0402
CAP, X7R 0.047uF 16V 10% 0603
CAP, X7R 0.01uF 16V 10% 0603
CAP, X7R 2200pF 25V 10% 0603
CAP, X7R 2200pF 25V 10% 0603
CAP, X7R 1000pF 25V 10% 0603
CAP, X7R 1000pF 25V 10% 0603
CAP, NPO,100pF,25V,10% 0603
CAP, NPO 22pF 50V 10% 0603
LED, GRN 0603
DIODE, DUAL SCHOTTKY, SOT23
RECTIFIER,GP,1A,50V,SMA
DIODE, GP 200V 200MA ,SOD323
HEADER, 3X2, 2mm
HEADER, 2X7, 2mm
HEADER, 2X1, 2mm
HEADER, 3X1,100MIL
FastDAACS
Manufacturer / Part #
AVX TPSE477M010R0050
AVX TPSE477M010R0050
KEMET T530X108M004ASE006
KEMET,T520D687M004ASE025
NICHICON UPL1C331MPH6
TAIYO YUDEN JMK316BJ106ML-T
AVX TAJA475M010R
AVX, 0603ZD105KAT
AVX, 0603YD224MAT
AVX 0603YC104KAT
AVX, 0402ZD104KAT
AVX 0603YC473KAT
AVX 0603YC103KAT
AVX 06033C222KAT2A
AVX 06033C222KAT2A
AVX 06033C102KAT2A
AVX 06033C102KAT2A
AVX 06033A101KAT2A
AVX 06035A220KAT
LITE ON LTST-C190KGKT
DIODES INC. BAT54S
DIODE INC, S1A
DIODES INC. BAV20WS
COMM CON 2202S-06G2
MOLEX, 87831-1420
COMM CON 3201S-02G2
COMM CON 3801S-03G2
10
