1.
Locate the two-pin pinout at the right of the IBM High IOPS Adapter:
2.
Plug in the connector:
NOTE
The pin closest to the PCIe connector is the negative pin.
3.
Replace the computer's access panel.
4.
Plug in the power cable and turn on the computer.
The external LED now displays both read and write operations performed on the IBM High IOPS Adapter.
Resume
the installation of your IBM High IOPS Adapter
IBM High IOPS Adapter - Hardware User Guide 2.2.3
__________________ __
|
__
15
