NOTE
To install the IBM High IOPS Duo Adapter, see the next section
For IBM High IOPS Adapter requirements, please see
Installation Instructions
Attention
Electrostatic discharge (ESD) can damage electronic components. Be sure that you are properly grounded
before beginning any hardware installation procedure.
1.
If you are installing the IBM High IOPS Adapter in a low-profile system, you need to use the half-height
bracket. Please refer to the
2.
Locate the serial number on your IBM High IOPS Adapter and record it for future reference.
3.
Turn off the computer and disconnect the power cable.
4.
Remove the computer's access panel. Locate an available x4 PCIe slot. (Consult your computer's
documentation for details on removing the panel and identifying PCIe slots.)
IBM High IOPS Adapter - Hardware User Guide 2.2.3
IBM High IOPS Adapter Installation
Half-Height Bracket Installation
IBM High IOPS Duo Adapter Installation
Hardware Requirements
.
section for details.
__________________ __
|
.
__
10
