4. Align the LEDs on the IBM High IOPS Adapter with the holes in the half-height bracket:
NOTE
Be sure the bracket tabs are on the backside of the device (opposite of heat sink).
5. Attach the half-height bracket using a Philips #1 tip screwdriver to tighten the two screws:
Attention Do not over-tighten! This can cause damage to the device.
6. Return to Step 2 of the Hardware Installation section to complete the install.

External Hard Drive LED (optional)

The IBM High IOPS Adapter includes a two-pin LED pinout for attaching to an external HDD access light. To attach
the LED:
