GENERAL
3. After disconnecting the MAF sensor connector(A) and
the breather hose(B), remove the air cleaner assem-
bly(C).
C
4. Disconnect the other breather hose(A), the Purge
Control Solenoid Valve(PCSV) hose, the Positive
Crankcase Ventilation (PCV) hose(C) and the Elec-
tronic Throttle Control(ETC) cooling hoses(D) and
connector(E).
C
D
A
www.CarGarage.ir
A
B
www.CarGarage.ir
5. Remove the wiring over the surge tank.
1) Disconnect the injection harness connector(A).
2) Disconnect the camshaft position sensor(CMP)
harness connector(B).
3) Disconnect the ground line(C).
4) Disconnect the ignition coil harness connec-
tor(D).
5) Disconnect the condensor connector(E).
6) Disconnect the variable induction system(VIS)
solenoid valve connector(G).
7) Disconnect the oil control valve(OCV) harness
SBLM16002L
connector(F).
8) Disconnect the injector wiring(H) and ignition coil
wiring(I).
E
SBLM16208L
SBLM16005L
C
A
E
F
G
H
I
EMA -9
B
D
SBLM16006L
SBLM16206L
