Specifications - Kia G6DB-3.3 Manual

EMA -2
GENERAL
SPECIFICATION
EE6CF939
Description
General
Type
Number of cylinders
Bore
Stroke
Total displacement
Compression ratio
Firing order
Valve timing
Intake
Exhaust
Cylinder head
Flatness of gasket surface
Flatness of manifold
mounting
Camshaft
Cam height
Journal outer
diameter
Bearing oil clearance
Opens(ATDC)
Closes(ABDC)
Opens(BBDC)
Closes(ATDC)
Intake
Exhaust
LH Intake
Camshaft
Exhaust
RH Intake
Camshaft
Exhaust
LH ,RH Intake
Camshaft
Exhaust
LH ,RH Intake
Camshaft
Exhaust
www.CarGarage.ir

Specifications

G6DB - 3.3
V-type, DOHC
6
92mm (3.6220in)
83.8mm (3.2992in)
3,342cc (203.86cu.in)
10.4
1-2-3-4-5-6
14˚
66˚
52˚
0˚
Less than 0.05mm (0.0019in)
[Less than 0.02mm (0.0008in) / 150x150]
Less than 0.1mm(0.0039in)
[Less than 0.03mm(0.001in)/110x110]
Less than 0.1mm(0.0039in)
[Less than 0.03mm(0.001in)/110x110]
46.3mm (1.8228in)
45.8mm (1.8031in)
46.3mm (1.8228in)
45.8mm (1.8031in)
No.1: 27.964 ~ 27.978mm (1.1009 ~ 1.1015in)
No.2,3,4: 23.954 ~ 23.970mm (0.9430
~ 0.9437in)
No.1: 27.964 ~ 27.978mm
(1.1009 ~ 1.1015in)
No.2,3,4: 23.954 ~ 23.970mm
(0.9430 ~ 0.9437in)
No.1: 0.027 ~ 0.057mm (0.0011 ~ 0.0022in)
No.2,3,4: 0.030 ~ 0.067mm (0.0012 ~ 0.0026in)
No.1: 0.027 ~ 0.057mm (0.0011 ~ 0.0022in)
No.2,3,4: 0.030 ~ 0.067mm (0.0012 ~ 0.0026in)
www.CarGarage.ir
ENGINE MECHANICAL SYSTEM
G6DA - 3.8
96mm (3.7795in)
87.0 mm(3.4252in)
3.778cc
(230.55cu.in)
10
66
52
0
46.8mm (1.8425in)
46.8mm(1.8425in)
Limit
