Kia G6DB-3.3 Manual page 3

GENERAL
Description
End play
Valve
Valve length
Stem outer diameter
Face angle
Thickness of
valvehead(margin)
Valve stem to valve
guide clearance
Valve guide
Inner diameter
Length
Valve seat
Width of seat contact
Seat angle
Valve spring
Free length
Load
Out of squareness
MLA
MLA outer diameter
Cylinder head tappet
bore inner diameter
MLA to tappet bore
clearance
Valve clearance
www.CarGarage.ir
Intake
Exhaust
Intake
Exhaust
Intake
Exhaust
Intake
Exhaust
Intake
Exhaust
Intake
Exhaust
Intake
Exhaust
Intake
Exhaust
Intake
Exhaust
Intake
Exhaust
Intake
Exhaust
www.CarGarage.ir
Specifications
G6DB - 3.3
→
105.27mm(4.1445in)
105.50mm (4.1535in)
5.465 ~ 5.480mm (0.2151 ~ 0.2157in)
5.458 ~ 5.470mm (0.2149 ~ 0.2153in)
45.25 ~ 45.75
1.56 ~ 1.86mm
(0.06142 ~ 0.07323in)
1.73 ~ 2.03mm
(0.06811 ~ 0.07992in)
0.020 ~ 0.047mm (0.00078 ~ 0.00185in)
0.030 ~ 0.054mm (0.00118 ~ 0.00212in)
5.500 ~ 5.512mm (0.2165 ~ 0.2170in)
5.500 ~ 5.512mm (0.2165 ~ 0.2170in)
41.8 ~ 42.2mm (1.6457 ~ 1.6614in)
41.8 ~ 42.2mm (1.6457 ~ 1.6614in)
1.15 ~ 1.45mm (0.05118 ~ 0.05709in)
1.35 ~ 1.65mm (0.05315 ~ 0.06496in)
44.75 ~ 45.20
44.75 ~ 45.20
43.86mm (1.7267in)
19.3±0.8kg/34.0mm (42.7±1.8 lb/1.3386in)
42.3±1.3kg/24.2mm (93.3±2.9 lb/0.9527in)
Less than 1.5
34.964 ~ 34.980mm (1.3765 ~ 1.3772in)
34.964 ~ 34.980mm (1.3765 ~ 1.3772in)
35.000 ~ 35.025mm (1.3779 ~ 1.3789in)
35.000 ~ 35.025mm (1.3779 ~ 1.3789in)
0.020 ~ 0.061mm (0.0008 ~ 0.0024in)
0.020 ~ 0.061mm (0.0008 ~ 0.0024in)
G6DA - 3.8
0.02 ~ 0.18mm
(0.0008 ~ 0.0071in)
0.07mm
(0.00275in)
0.09mm
(0.00354in)
0.07mm(0.0027in)
0.07mm(0.0027in)
EMA -3
Limit
