Kia G6DB-3.3 Manual page 6

EMA -6
TIGHTENING TORQUE
Item
Crankshaft pulley bolt
Timing chain cover bolt B
Timing chain cover bolt C
Timing chain cover bolt D
Timing chain cover bolt E
Timing chain cover bolt F
Timing chain cover bolt G
Timing chain cover bolt H
Timing chain cover bolt I
Timing chain cover bolt J
Cam to cam guide bolt
Timing chain auto tensioner bolt
Timing chain auto tensioner nut
Timing chain guide bolt
Oil pump chain cover bolt
Oil pump chain tensioner bolt
Oil pump chain guide bolt
Oil pump chain sprocket bolt
Lower oil pan bolt
Drive belt auto tensioner bolt(M12)
Drive belt auto tensioner bolt(M8)
Drive belt idler bolt
OCV(oil control valve) bolt
Cylinder head bolt
Cylinder head bolt
CVVT ＆ exhaust cam sprocket bolt
Camshaft bearing cap bolt
Cylinder head cover bolt
Connecting rod bearing bolt
Main bearing cap inner bolt(M11)
Main bearing cap outer bolt(M8)
Main bearing cap side bolt(M8)
Oil drain cover bolt
Rear oil seal case bolt
Baffle plate bolt
Upper oil pan bolt
www.CarGarage.ir
Nm
Quantity
1 284.2 ~ 303.8
17 18.62 ~ 21.56
4 9.80 ~ 11.76
1 58.80 ~ 68.80
1 58.80 ~ 68.80
2 24.50 ~ 26.46
4 21.56 ~ 23.52
1 9.80 ~ 11.76
1 9.80 ~ 11.76
1 9.80 ~ 11.76
4 9.80 ~ 11.76
2 9.80 ~ 11.76
2 9.80 ~ 11.76
4 19.60 ~ 24.50
3 9.80 ~ 11.76
1 9.80 ~ 11.76
2 9.80 ~ 11.76
1 18.62 ~ 21.56
13 9.80 ~ 11.76
1 81.4 ~ 85.3
1 29.4 ~ 33.3
1 53.90 ~ 57.82
2 9.80 ~ 11.76
16
39.2 + 120˚ + 90˚
1 18.62 ~ 23.52
4 64.68 ~ 76.44
32 9.80 ~ 11.76
38 9.80 ~ 11.76
12
19.60 + 90˚
8
49.00 + 90˚
8
19.60 + 120˚
6 29.40 ~ 31.36
6 9.80 ~ 11.76
6 9.80 ~ 11.76
12 9.80 ~ 11.76
16 9.80 ~ 11.76
www.CarGarage.ir
ENGINE MECHANICAL SYSTEM
kgf.m
29.0 ~ 31.0
1.9 ~ 2.2
1.0 ~ 1.2
6.0 ~ 7.0
6.0 ~ 7.0
2.5 ~ 2.7
2.2 ~ 2.4
1.0 ~ 1.2
1.0 ~ 1.2
1.0 ~ 1.2
1.0 ~ 1.2
1.0 ~ 1.2
1.0 ~ 1.2
2.0 ~ 2.5
1.0 ~ 1.2
1.0 ~ 1.2
1.0 ~ 1.2
1.9 ~ 2.2
1.0 ~ 1.2
8.3 ~ 8.7
3.0 ~ 3.4
5.5 ~ 5.9
1.0 ~ 1.2
4.0 + 120˚ + 90˚
1.9 ~ 2.4
6.6 ~ 7.8
1.0 ~ 1.2
1.0 ~ 1.2
2.0 + 90˚
5.0 + 90˚
2.0 + 120˚
3.0 ~ 3.2
1.0 ~ 1.2
1.0 ~ 1.2
1.0 ~ 1.2
1.0 ~ 1.2
lb.ft
209.76 ~ 224.22
13.74 ~ 15.91
7.23 ~ 8.68
43.40 ~ 50.63
43.40 ~ 50.63
18.08 ~ 19.53
15.91 ~ 17.36
7.23 ~ 8.68
7.23 ~ 8.68
7.23 ~ 8.68
7.23 ~ 8.68
7.23 ~ 8.68
7.23 ~ 8.68
14.17 ~ 18.08
7.23 ~ 8.68
7.23 ~ 8.68
7.23 ~ 8.68
13.74 ~ 15.91
7.23 ~ 8.68
60.0 ~ 62.9
21.7 ~ 24.6
39.78 ~ 42.67
7.23 ~ 8.68
28.93+ 120˚ +
90˚
13.74 ~ 17.36
47.74 ~ 56.42
7.23 ~ 8.68
7.23 ~ 8.68
14.46 + 90˚
36.16 + 90˚
14.46 + 120˚
21.70 ~ 23.14
7.23 ~ 8.68
7.23 ~ 8.68
7.23 ~ 8.68
7.23 ~ 8.68
