Parameters
6-74 Terminal 45 Output Max Scale
Scale for the maximum output (20 mA) of the analog signal at
terminal 45.
Range:
Function:
100 %
[0 - 200 %]
Set the value to be the percentage
*
of the full range of the variable
selected in parameter 6-71 Terminal
45 Analog Output.
Current
(mA)
Illustration 3.9 Output Maximum
Scale
6-76 Terminal 45 Output Bus Control
Range:
Function:
0
[0 - 16384 ]
Holds the level of analog output if
*
controlled by bus.
3.7.5 6-9* Analog/Digital Output 42
Parameters for configuring the limits for analog/digital
output terminal 42. Analog outputs are current outputs:
0/4–20 mA. Resolution on analog outputs is 12 bit. Analog
output terminals can also be set up as digital output.
6-90 Terminal 42 Mode
Set terminal 42 to act as analog output or as digital output.
Option:
Function:
[0]
0-20 mA
*
[1]
4-20 mA
[2]
Digital Output
6-91 Terminal 42 Analog Output
Select the function of terminal 42 as an analog current output.
See also parameter 6-90 Terminal 42 Mode.
Option:
Function:
[0]
No operation
*
[100]
Output
0–100 Hz
frequency
[101]
Reference
Min
[102]
Feedback
Min
[103]
Motor Current
0–I
[106]
Power
0–P
MG18P202
Programming Guide
20
0/4
0%
Analogue
Analogue
100%
Variable
output
Output
for
Min Scale
Max Scale
output
par. 6-73
par. 6-74
example:
Power
–Max
Ref.
Ref.
–Max
FB
FB
max
nom
Danfoss A/S © 06/2019 All rights reserved.
6-91 Terminal 42 Analog Output
Select the function of terminal 42 as an analog current output.
See also parameter 6-90 Terminal 42 Mode.
Option:
Function:
[139]
Bus Control
0–100%
[254]
DC Link
Voltage
6-92 Terminal 42 Digital Output
Select the function of Terminal 42 as an analog current output.
See also parameter 6-90 Terminal 42 Mode. See
parameter 5-40 Function Relay for description of the choices.
Option:
Function:
[0]
No operation
*
[1]
Control Ready
[2]
Drive ready
[3]
Drive ready/
remote control
[4]
Standby / no
warning
[5]
Drive running
[6]
Running / no
warning
[7]
Run in
range/no
warning
[8]
Run on ref/no
warning
[9]
Alarm
[10]
Alarm or
warning
[12]
Out of current
range
[13]
Below current,
low
[14]
Above current,
high
[16]
Below speed,
low
[17]
Above speed,
high
[19]
Below
feedback, low
[20]
Above
feedback, high
[21]
Thermal
warning
[22]
Ready, no
thermal
warning
[23]
Remote, ready,
no thermal
warning
[24]
Ready, Voltage
OK
3
3
39
