Description:

The Ocean Matrix OMX-01KVKV0002 extends 1080p 60Hz HDMI & KVM signals up to
60 meters / 197 feet. With local HDMI loop-out, IR control, and 3.5mm audio support, the
OMX-01KVKV0002 is the ideal unit for HDMI KVM extension.

Features:

Supports Resolutions up to 1080p/60Hz
Local HDMI Loop-Out Functionality
Supports transmission up to 60 meters/197 feet
Low Power Consumption & Low Operating Temperature
Both the TX and RX Units Support 3.5mm Stereo Audio
IR Control Functionality
Supports Mouse and Keyboard Extension

Specifications:

Transmission Distance: Up to 60m/197ft via CAT5e/6
HDMI Input: 1080p/1080i/720p/576p/576i/480p/480i
HDMI Output: 1080p/1080i/720p/576p/576i/480p/480i
Max Bandwidth: 150MHz
Max Baud Rate: 4.5Gbps
Input Video Signal: 0.5~1.5Volts p-p
Output DDC Signal: 5 Volts p-p (TTL)
Input HDMI Cable Distance: ≤ 10m AWG26 HDMI Standard Cable
Output HDMI Cable Distance: ≤ 15m AWG26 HDMI Standard Cable
TX Max Working Current: 450mA
RX Max Working Current: 350mA
Power Adapter Format: Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
Operating Temperature range: 5 to 113°F (-15 to +45°C)
Operating Humidity Range: 5 to 90% RH (No Condensation)
TX Weight: 108g
RX Weight: 108g
Dimensions (LxWxH): 4.78 x 1.97 x 0.74" (122 x 50 x 19 mm)
Weight: 0.24 lbs / 3.8 oz / 107 grams
