RH LUCIDA COFFEE TABLE Instructions page 2

Advertisement

5.
Insert the remaining silicon washers between
the glass top and the leg frames, as shown in
Figure 02.
To keep the table from wobbling, insert the
6.
headless socket screw bolt (1) into the cavities
underneath the leg frames. Tighten all the bolts
with the Allen wrench (4) to a snug fit, as shown
in Figure 03-A.
Place the coffee table in the desired location
7.
and check whether leveling is necessary. If so,
slightly tilt the table and turn the levelers
clockwise to raise and counterclockwise to
lower, as shown in Figure 03-B. Repeat
adjustment procedures if necessary after the
furniture settles on rugs or on carpeted surface.
11/1/18
FIGURE 02
SILICON
WASHER
FIGURE 03
FIGURE 03-A
HEADLESS
SOCKET
SCREW
BOLT
FIGURE 03-B
Lucida Coffee Table - Page 2 of 2
