RH LUCIDA COFFEE TABLE Instructions

Advertisement

Quick Links

Thank you for choosing this quality product. Be sure to check all packaging materials carefully for small parts that may
have become loose during shipment and place all parts on a non-abrasive surface.
!
WARNING: Table parts can be cumbersome and heavy; therefore, the assistance of two or more
people is recommended in order to prevent personal injury and ensure the table is not damaged during the
assembly process.
PARTS INCLUDED
A [1] GLASS TOP
B [2] LEG FRAMES
ASSEMBLY INSTRUCTIONS
1. A work bench or small, sturdy table is
required for assembly. Place the glass top
(A) onto the work bench or table. Ensure the
ends of the glass overhang the bench.
2. In the hardware pack, locate the metal
washers (3) and silicon washers (2). Place
them in the cavities of the leg frames, as
shown in Figure 01.
3. Gently slide the cavity of the leg frames (B)
onto both ends of the glass top up to the
end of the protective film, as shown in
Figure 01.
4. After inserting the leg frames, remove the
coffee table from the work bench and set it
on the floor. IMPORTANT: Four or more
people are recommended when lifting the
coffee table.
11/1/18
LUCIDA COFFEE TABLE INSTRUCTIONS
FIGURE 01
SILICON
WASHER
METAL
WASHER
HARDWARE INCLUDED
NO.
ITEM
DESCRIPTION
Headless Socket Screw Bolt
1
2
3
4
QTY.
4 PCS
Silicon Washer
4 PCS
Metal Washer
8 PCS
2 PCS
Allen Wrench
Page 1 of 2
