Page 1
May 2022 Click the button Scan the QR code to watch the to watch the assembly video assembly video 3 SEATER GETAWAY SOFA...
Page 2
What’s in the box: 104-9175 104-9176 104-9177 104-9178 104-9123...
Page 3
Assemble the metal frame by connecting the four corners together. Make sure brackets are facing outwards and metal ledges are facing forwards. Bracket Metal ledge Ensure the metal frames should be flush with each other before moving to the next step.
Page 4
Lock the metal frame together by inserting 4 x gumnuts into the corners as shown, and tighten completely. Screw on the legs with washers until fully tightened.
Page 5
Flip the frame over onto the legs and insert the middle beam. If you are connecting an additional modular sofa to this sofa, please refer to the assembly instructions located in the seat-cushion box of your Chaise or Corner which shows you how to proceed. Note the di erence between the backrest and the armrests: The backrest brackets are further apart than the armrest brackets, and the backrest is wider.
Page 6
Insert the armrests and backrests by aligning the brackets and pushing all the way down. Insert the gumnuts through the metal frame into the armrests and backrests and tighten fully.
Page 7
Place the seat base frames onto the metal ledges on the metal frame, making sure to place the label side down. This side up This side down Align and push in the storage boxes under the front metal beam.
Page 8
Place seat cushions, backrest cushions and armrest cushions onto the frame. Enjoy.
Page 9
Product Information and Care FABRIC Regular Care (Weekly) • Vacuum regularly using low suction • Protect from direct sunlight • After use, you can floof the cushions to bring them back to shape Cleaning • Remove any spills immediately by gently blotting any liquid stands with a clean cloth. Scoop any sauces up before blotting the remaining sauces •...
