- Page 1 Jan 2024 Click the button to watch the assembly video Chaise Module BANGALOW MODULAR SOFA...
- Page 2 What’s in the box*: Click the button to watch the assembly video *Not to scale BOX 1 hook Chaise Module Cushion Chaise Module Frame Large Backrest Cushion Insert BOX 2 BOX 3 Large Backrest Cushion Cover Large Armrest/ Backrest Module Cover Chaise Module Cushion Cover...
- Page 3 Remove the chaise module cushion, Click the button to watch the backrest cushion insert, legs and assembly video hooks from the chaise module frame. Screw the legs into the seat module frame and rotate the centre bar by 90 degrees. 90°...
- Page 4 Align the chaise module labels and Click the button to watch the place the chaise module cushion on assembly video the frame, then pull the ‘skirt’ down. Ensure all yellow The velcro is colour tags align coordinated Flip the module to secure the ‘skirt’ velcro in place. Flip the module back over.
- Page 5 Click the button Grab the chaise module cover, to watch the align the chaise module labels assembly video and tug the cover into place. Ensure all yellow The velcro is colour tags align coordinated Flip the module and secure the front base velcro then the front side velcro in place.
- Page 6 Secure the rear velcro then Click the button to watch the the rear side velcro in place. assembly video Grab the armrest/backrest module cover, align the frame label with the cover label then tug the cover onto the frame and secure the velcro in place.
- Page 7 Place the backrest cushion insert Click the button to watch the into the backrest cushion cover assembly video and close the zip. Massage the cushion into shape if required Align the wedge brackets to connect the armrest/backrest module to the chaise module and slide all the way down.
- Page 8 Click the button To build out your Bangalow to watch the Sofa, install the hooks on the assembly video module and push all the way down. Align the front and back of the seats then lift the next module onto the hooks to connect them together. Repeat until all modules are connected.
- Page 9 Place your backrest cushions onto the modules..use the “Armrest/Backrest Module” assembly instructions to complete your Bangalow Modular Sofa.
- Page 10 Product Information and Care LINING FABRIC Regular Care (Weekly) • Vacuum regularly using low suction. • Protect from direct sunlight. Spot Cleaning • Remove any spills immediately by gently blotting any liquid with a clean cloth. • Scoop up any solids before blotting the remaining liquid. •...
- Page 11 Click the button to watch the assembly video don’t forget to recycle.
