What’s in the box*: *Not to scale Front Rail Left Armrest Backrest Back Rail Centre Right Armrest Back Panel Beam 104-9376 Backrest Cushion Rounded Covers Seat Panel Front Rail Cover Backrest Cushions Non-Rounded Seat Panel Left Armrest Cover Seat Cushion Covers Backrest Cover...
Page 3
Click the button Lay the back rail down with the to watch the corner connections facing up. assembly video Connect the back rail to the armrests using the corner connections. Position of pins on armrests should be against the back panel...
Page 4
Click the button Connect the front rail to the armrests to watch the using the corner connections. assembly video Firmly screw in legs into corner connection.
Page 5
Click the button Firmly screw leg into the centre beam. to watch the assembly video Ensure centre beam is in correct orientation before screwing leg in Secure the centre beam with two round-head gumnuts.
Page 6
Click the button Hold the front panel and carefully to watch the lower the sofa onto its legs. assembly video Place the seat panels onto the frame. Ensure the rounded seat panels are in the outer positions...
Page 7
Click the button Guide the backrest hooks to watch the into the upper armrest pins. assembly video Align the holes and screw in the tri-head gumnuts.
Page 8
Guide the backrest panel hooks into the Click the button to watch the lower armrest pins then rotate and press assembly video against the backrest to secure. Ensure metal plate on back rail is not visable when assembled Place armrest cover over armrest and secure with velcro at the back, bottom and inside.
Page 9
Click the button Place front rail cover over one side of to watch the the front rail and secure with velcro assembly video along the length of the top and bottom, then tuck the cover on the other side. Attach front side velcro of the backrest cover to the velcro on the armrest cover, then attach the front bottom velcro of the backrest cover to the base of the backrest.
Page 10
Click the button Attach back side velcro of the backrest to watch the cover to the velcro on the back panel assembly video and back rail, then attach the back bottom velcro of the backrest cover to the base of the back rail. Place the seat cushions in the seat cushion covers, then zip the cover closed.
Page 11
Click the button Place the backrest cushions in the to watch the backrest cushion covers, then zip assembly video the cover closed. Ensure zips are aligned to correctly orientate the seat cushion covers and the seat cushions Place the seat cushions onto the sofa.
Page 12
Click the button Place the backrest to watch the cushions onto the sofa. assembly video Enjoy!
Product Information and Care Click the button to watch the assembly video FABRIC Lining Fabric • Vacuum regularly using low suction. • Protect from direct sunlight. Removable Covers • For correct care of the removable covers refer to the care label inside covers for additional cleaning instructions.
Page 14
Click the button Click the button to watch the to watch the assembly video assembly video don’t forget to recycle.
