- Page 1 Click the button to watch the assembly video SUFFOLK SOFA 2.5 SEATER...
-
Page 2: What's In The Box
What’s in the box*: *Not to scale Front Rail Left Armrest Backrest Back Rail Right Armrest Back Panel Backrest Front Rail Cover Cushion Covers Rounded Seat Panel Backrest Cover Backrest Cushions Non-Rounded Seat Panel Left Armrest Cover Seat Cushion Tri-Head Covers Gumnut 104-9379... - Page 3 Lay the back rail down with the corner Click the button to watch the connections facing up. assembly video Connect the back rail to the armrests using the corner connections. Position of pins on armrests should be against the back panel...
- Page 4 Connect the front rail to the armrests Click the button to watch the using the corner connections. assembly video Firmly screw in legs into corner connection.
- Page 5 Hold the front panel and carefully lower Click the button to watch the the sofa onto its legs. assembly video Place the seat panels onto the frame. Ensure the rounded seat panels are in the outer positions...
- Page 6 Click the button Guide the backrest hooks into to watch the the upper armrest pins. assembly video Align the holes and screw in the tri-head gumnuts.
- Page 7 Guide the backrest panel hooks into the Click the button to watch the lower armrest pins then rotate and press assembly video against the backrest to secure. Ensure metal plate on back rail is not visable when assembled Place armrest cover over armrest and secure with velcro at the back, bottom and inside.
- Page 8 Place front rail cover over one side of the Click the button to watch the front rail and secure with velcro along the assembly video length of the top and bottom, then tuck the cover on the other side. Attach front side velcro of the backrest cover to the velcro on the armrest cover, then attach the front bottom velcro of the backrest cover to the base of the backrest.
- Page 9 Attach back side velcro of the backrest cover Click the button to watch the to the velcro on the back panel and back rail, assembly video then attach the back bottom velcro of the backrest cover to the base of the back rail. Place the seat cushions in the seat cushion covers, then zip the cover closed.
- Page 10 Click the button Place the backrest cushions in the backrest to watch the cushion covers, then zip the cover closed. assembly video Ensure zips are aligned to correctly orientate the seat cushion covers and the seat cushions Place the seat cushions onto the sofa.
- Page 11 Click the button Place the backrest cushions onto the sofa. to watch the assembly video Enjoy!
-
Page 12: Safety And Use
Product Information and Care FABRIC Lining Fabric • Vacuum regularly using low suction. • Protect from direct sunlight. Removable Covers • For correct care of the removable covers refer to the care label inside covers for additional cleaning instructions. Spot Cleaning •... - Page 13 Click the button to watch the assembly video don’t forget to recycle.
