SDX
Extend DVI-D, RS232, Stereo Audio & USB
USER MANUAL
SDX-2P
Dual DVI-D, USB K/M, Audio and Dual RS-232 Extender
SDX-4P
Quad DVI-D, USB K/M, Audio and Dual RS-232 Extender
SDX-PLUS
Single DVI-D, USB K/M and RS-232 Extender
series
Designed and Manufactured in the USA
1-800-284-2131
www.smartavi.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SMART-AVI SDX Series
Summary of Contents for SMART-AVI SDX Series
- Page 1 series Extend DVI-D, RS232, Stereo Audio & USB USER MANUAL SDX-2P Dual DVI-D, USB K/M, Audio and Dual RS-232 Extender SDX-4P Quad DVI-D, USB K/M, Audio and Dual RS-232 Extender SDX-PLUS Single DVI-D, USB K/M and RS-232 Extender Designed and Manufactured in the USA 1-800-284-2131 www.smartavi.com...
-
Page 2: Table Of Contents
OVERVIEW TECHNICAL SPECIFICATIONS_________________________________________________________________ WHAT’S IN THE BOX?________________________________________________________________________ FRONT AND REAR___________________________________________________________________________ INSTALLATION_______________________________________________________________________________ TROUBLESHOOTING_________________________________________________________________________ TECHNICAL SUPPORT________________________________________________________________________ LIMITED WARRANTY STATEMENT____________________________________________________________ DVI-D, RS232, Stereo Audio & USB Extender... -
Page 3: Technical Specifications
Technical Specifications VIDEO Format DVI-D Single Link Max. Pixel Clock 165 MHz SDX-2P (2) DVI-D (Single-Link) Input Interface (TX) SDX-4P (4) DVI-D (Single-Link) SDX-PLUS (1) DVI-D (Single-Link) SDX-2P (2) DVI-D (Single-Link) Output Interface (RX) SDX-4P (4) DVI-D (Single-Link) SDX-PLUS (1) DVI-D (Single-Link) Resolution Up to 1920 x 1200 @ 60 Hz 5 volts p-p (TTL) -
Page 4: What's In The Box
What’s in the box? PART NO. Q-TY DESCRIPTION SDX-TX Unit 1/2/4 Port DVI-D, USB 1.1, Audio and RS-232 Transmitter SDX-RX Unit 1/2/4 Port DVI-D, USB 1.1, Audio and RS-232 Receiver PS5VD2A PS5VD2A Power Supply User Manual SDX-2P-tX Rear SDX-2P-tX front SDX-2P-RX Rear SDX-2P-RX front DVI-D, RS232, Stereo Audio &... -
Page 5: Installation
INSTALLATION 1. Power off all devices. 2. Connect two DVI-D sources (computer) to the two DVI-D ports on the back of the SDX-TX2P. 3. Connect a USB source (computer) to the USB port on the SDX-TX2P. 4. Optionally connect RS-232 and IR for control functions. 5. - Page 6 INSTALLATION (continue) 1. Power off all devices. 2. Connect four DVI-D sources (computer) to the four DVI-D ports on the back of the SDX-TX4P. 3. Connect a USB source (computer) to the USB port on the SDX-TX4P. 4. Optionally connect RS-232 and IR for control functions. 5.
- Page 7 INSTALLATION (continue) 1. Power off all devices. 2. Connect a DVI-D source (computer) to the DVI-D port on the SDX-Plus-TX. 3. Connect a USB source (computer) to the USB port on the SDX-Plus-TX. 4. Optionally connect RS-232 and IR for control functions. 5.
-
Page 8: Troubleshooting
Troubleshooting No Power • Make sure that the power adapter is securely connected to the power connector of the unit. • Check the output voltage of the power supply and make sure that the voltage value is around 12VDC. • Replace the power supply. No Video •... -
Page 9: Limited Warranty Statement
Limited warranty statement A. Extent of limited warranty SmartAVI, Inc. warrants to the end-user customers that the SmartAVI product specified above will be free from defects in materials and workmanship for the duration of 1 year, which duration begins on the date of purchase by the customer. Customer is responsible for maintaining proof of date of purchase. - Page 10 NOTICE The information contained in this document is subject to change without notice. SmartAVI makes no warranty of any kind with regard to this material, including but not limited to, implied warranties of merchantability and fitness for particular purpose. SmartAVI will not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance or use of this material.
