SM-MST
MST DP KVM with MULTIPLE 4K HDMI Out
USER MANUAL
SM-MST-2S
2 Port KVM MST with Dual 4K HDMI Out
SM-MST-2D
2 Port KVM MST with Quad 4K HDMI Out
SM-MST-4S
4 Port KVM MST with Dual 4K HDMI Out
SM-MST-4D
4 Port KVM MST with Quad 4K HDMI Out
2/4 Port KVM MST with Dual or Quad 4K HDMI Out
1-800-284-2131
www.smartavi.com
series
1
Advertisement
Related Manuals for SMART-AVI SM-MST-2S
Summary of Contents for SMART-AVI SM-MST-2S
- Page 1 SM-MST series MST DP KVM with MULTIPLE 4K HDMI Out USER MANUAL SM-MST-2S 2 Port KVM MST with Dual 4K HDMI Out SM-MST-2D 2 Port KVM MST with Quad 4K HDMI Out SM-MST-4S 4 Port KVM MST with Dual 4K HDMI Out...
-
Page 2: Table Of Contents
Table of content TECHNICAL SPECIFICATIONS_____________________________________________________________ 3-4 WHAT’S IN THE BOX?_____________________________________________________________________ 4 FRONT AND REAR________________________________________________________________________ 4 INSTALLATION____________________________________________________________________________ 5-7 LED’s BEHAVIOR__________________________________________________________________________ 8 SYSTEM OPERATION______________________________________________________________________ 9 TROUBLESHOOTING______________________________________________________________________ 9 TECHNICAL SUPPORT_____________________________________________________________________ 9 LIMITED WARRANTY STATEMENT________________________________________________________ 10 2/4 Port KVM MST with Dual or Quad 4K HDMI Out... -
Page 3: Technical Specifications
SM-MST-2S (2) DisplayPort1.2a Input Interface (TX) SM-MST-2D / SM-MST-4S (4) DisplayPort1.2a SM-MST-4D (8) DisplayPort1.2a SM-MST-2S / SM-MST-4S (2) HDMI Output Interface (RX) SM-MST-2D / SM-MST-4D (4) HDMI Input Resolution Up to 4K (3840 x 2160 @ 60 Hz) Output Resolution... -
Page 4: What's In The Box
2/4 Port KVM MST with Dual or Quad 4K HDMI Out PS12V2A 12V DC, 2A (minimum) power adapter with center-pin positive polarity. User Manual SM-MST-2S rear SM-MST-2S FRONT SM-MST-2D rear SM-MST-2D FRONT 2/4 Port KVM MST with Dual or Quad 4K HDMI Out... - Page 5 SM-MST-4S rear SM-MST-4S FRONT SM-MST-4D rear SM-MST-4D FRONT 2/4 Port KVM MST with Dual or Quad 4K HDMI Out...
-
Page 6: Installation
Application diagram SM-MST-2S The SM-MST-2S converts a single DisplayPort 1.2 input signal to two separate HDMI Output connections through advanced MultiStream Transport technology. This allows a user to extend their display and achieve resolutions of up to 4K (3840 x 2160 @ 30 Hz) on each connected monitor without from single DP port. - Page 7 Application diagram SM-MST-2D The SM-MST-2D converts a dual DisplayPort 1.2 input signal to four separate HDMI Output connections through advanced MultiStream Transport technology. This allows a user to extend their display and achieve resolutions of up to 4K (3840 x 2160 @ 30 Hz) on each connected monitor without from single DP port.
- Page 8 Application diagram SM-MST-4S The SM-MST-4S converts a single DisplayPort 1.2 input signal to two separate HDMI Output connections through advanced MultiStream Transport technology. This allows a user to extend their display and achieve resolutions of up to 4K (3840 x 2160 @ 30 Hz) on each connected monitor without from single DP port.
- Page 9 Application diagram SM-MST-4D The SM-MST-4D converts a dual DisplayPort 1.2 input signal to four separate HDMI Output connections through advanced MultiStream Transport technology. This allows a user to extend their display and achieve resolutions of up to 4K (3840 x 2160 @ 30 Hz) on each connected monitor without from single DP port.
-
Page 10: Troubleshooting
Troubleshooting No Power Make sure that the power adapter is securely connected to the power connector of the unit. Check the output voltage of the power supply and make sure that the voltage value is around 12VDC. Replace the power supply. No Video ... -
Page 11: Limited Warranty Statement
Limited warranty statement A. Extent of limited warranty SmartAVI, Inc. warrants to the end-user customers that the SmartAVI product specified above will be free from defects in materials and workmanship for the duration of 1 year, which duration begins on the date of purchase by the customer. - Page 12 NOTICE The information contained in this document is subject to change without notice. SmartAVI makes no warranty of any kind with regard to this material, including but not limited to, implied warranties of merchantability and fitness for particular purpose. SmartAVI will not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance or use of this material.
