Symbols For The Language Selection; Status And Warning Symbols - LEYBOLD GRAPHIX ONE Operation Manual

4.4.2

Symbols for the Language Selection

Symbol Designation
Language selection
English
German
Chinese
French
Italian
Japanese
Spanish
Korean
Russian
Polish
Turkish
Table 4 – Symbols for language selection
4.4.3

Status and Warning Symbols

Symbol Designation
Status Calibration
Factor
Status Offset
Status HV On
Status HV 1 On
Status HV 2 On
Status Degas
Notice
Error
SP Off
SP On
Table 5 – Status indicating and warning symbols
GA300553102_002_C2 – 04/2017
Start language selection menu
Select menu language EN (English)
Select menu language DE (German)
Select menu language CN (Chinese)
Select menu language FR (French)
Select menu language IT (Italian)
Select menu language JP (Japanese)
Select menu language ES (Spanish)
Select menu language KN (Korean)
Select menu language RU (Russian)
Select menu language PL (Polish)
Select menu language TR (Turkish)
Gas type correction factor differs from 1
Offset differs from 0
PENNINGVAC sensor is ON
Filament 1 of the IONIVAC sensor is ON
Filament 2 of the IONIVAC sensor is ON
Degassing is active
Sensor status indicates "Notice"
Sensor status indicates "Error"
Switching threshold disabled (pressure high)
Switching threshold enabled (pressure low)
