Specifications

Display
Measurement principle
Range
Electrode length
Electrode pins
Auto Power OFF
Power supply
Meter housing
Operating Temperature
Operating Humidity
Dimensions
Weight
Description
Meter Description
1. Measurement pins
2. Low battery icon
3. LCD measurement reading
4. Wood group designators
5. Units of measure
6. External moisture sensor input
7. Remote temperature probe jack
8. Temperature units button
9. Wood group letter selector button
10. Power ON-OFF button
Note that the battery compartment is
located on the rear of the instrument.
Dual measurement scale LCD with bargraph metering
Electrical resistance
Wood: 6 to 44%
0.3" (8mm)
Integrated, replaceable
After approx. 15 minutes
Two (2) 'AAA' 1'5V batteries
Impact-proof plastic
o o
32 to 104 F (0 to 40 C)
85% Relative Humidity maximum
5.1 x 1.6 x 1.0" (130 x 40 x 25mm)
3.5 oz. (100g)
1
2
3
4
3
5
6
7
8
9
10
MO220 V1..2 4/10
