Sauder 414443 Assembly Instructions Manual

Sofa table
Hide thumbs

Advertisement

Quick Links

Download this manual
sauder.com
Sofa Table
Carson Forge Collection | Model 414443
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Gets on your couch' s
good side.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-22
Français pg 23-25
Español pg 26-28
Lot # 361493
04/03/14
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading
Need help?

Need help?

Do you have a question about the 414443 and is the answer not in the manual?

Questions and answers

Related Manuals for Sauder 414443

Summary of Contents for Sauder 414443

  • Page 1 Carson Forge Collection | Model 414443 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 BACK (1) SIDE SKIRT (2) D75 DRAWER BACK (2) BRACE (1) RIGHT DRAWER FRONT (1) D83 RIGHT DRAWER SIDE (2) RIGHT REAR LEG (1) LEFT DRAWER FRONT (1) D84 LEFT DRAWER SIDE (2) LEFT REAR LEG (1) Page 2 414443 www.sauder.com/services...
  • Page 3 Now you know Part Identifi cation our ABCs. D721 D721 www.sauder.com/services 414443 Page 3...
  • Page 4 CAM COVER - 2 BLACK 1-7/8" FLAT HEAD SCREW - 1 GOLD 5/16" FLAT HEAD SCREW - 16 30S BLACK 1-9/16" FLAT HEAD SCREW - 8 SILVER 5/8" MACHINE SCREW - 6 BROWN 9/16" LARGE HEAD SCREW - 17 Page 4 414443 www.sauder.com/services...
  • Page 5 Do not insert CAM DOWELS into these HIDDEN CAMS. Arrow Do not insert CAM DOWELS into these edges. Arrow Insert the metal end of the CAM DOWEL into the HIDDEN CAM. (32 used) Arrow (18 used) Arrow Hole www.sauder.com/services 414443 Page 5...
  • Page 6 Step 2 Turn fourteen CAM SCREWS (8F) into the LEGS (I, J, K, and L). å Remember: NOTE: Be sure to use the exact holes shown. å Righty tighty. Lefty loosey. (14 used) Page 6 414443 www.sauder.com/services...
  • Page 7 Step 3 Fasten a CORNER ACCENT (8E) to each FRONT LEG (K and L). å Use two SILVER 5/8" MACHINE SCREWS (15S). SILVER 5/8" MACHINE SCREW (2 used in this step) Angled edge Angled edge www.sauder.com/services 414443 Page 7...
  • Page 8 Inspect the parts thoroughly before assembling. Disassembly of glued Surface with parts is extremely diffi cult. HIDDEN CAMS Angled edge Edge and surface with HIDDEN CAMS Finished edge Finished edge Surface with Angled edge HIDDEN CAMS Angled edge Page 8 414443 www.sauder.com/services...
  • Page 9 NOTE: The CABINET RAILS are marked "CABINET RIGHT" å and "CABINET LEFT" for easy identifi cation. Roller end GOLD 5/16" FLAT HEAD SCREW (8 used in this step) Finished edge Roller end Roller end Roller end www.sauder.com/services 414443 Page 9...
  • Page 10 Cross the METAL BARS (26M) and line up the center å holes in the BARS. Then, fasten the METAL BARS to the MODESTY PANEL (F). Use fi ve BROWN 9/16" LARGE HEAD SCREWS (40S). BROWN 9/16" LARGE HEAD SCREW (13 used in this step) Page 10 414443 www.sauder.com/services...
  • Page 11 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees www.sauder.com/services 414443 Page 11...
  • Page 12 Inspect the parts thoroughly before w i t h assembling. Disassembly of glued H I D parts is extremely diffi cult. D E N Roller end Fill the holes 1/4 to 1/2 full with GLUE. Page 12 414443 www.sauder.com/services...
  • Page 13 Fasten the BRACE (H) to the RIGHT END (A). Tighten two å HIDDEN CAMS. Minimum 190 degrees Edge and surface with HIDDEN CAMS S u r f a c w i t h H I D D E N Rounded edge www.sauder.com/services 414443 Page 13...
  • Page 14 NOTE: Be sure the WOOD DOWEL (15F) in the LEFT å REAR LEG (J) inserts into the hole in the BACK SKIRT (M). Wipe away the excess GLUE. Fill the holes 1/4 to 1/2 full with GLUE. Maximum Arrow 210 degrees Minimum 190 degrees Page 14 414443 www.sauder.com/services...
  • Page 15 BACK SKIRT (M). Use four BROWN 9/16" LARGE HEAD SCREWS (40S) through the METAL BARS (26M) and into the holes in the BACK and BACK SKIRT. BROWN 9/16" LARGE HEAD SCREW (4 used in this step) www.sauder.com/services 414443 Page 15...
  • Page 16 Step 12 Push a FOOT (10E) over the bottom edge of å each LEG (I, J, K, and L). With a hammer, gently tap a TACK GLIDE (12E) å through the holes of the FEET (10E). Page 16 414443 www.sauder.com/services...
  • Page 17 Fasten the UPRIGHT (C) to the BRACE (H). Use a BLACK å legs. And, you know, 1-7/8" FLAT HEAD SCREW (2S). your arms. Finished edge Surface with HIDDEN CAMS BLACK 1-7/8" FLAT HEAD SCREW (1 used in this step) www.sauder.com/services 414443 Page 17...
  • Page 18 LEGS (I, J, K, and L). Wipe away the excess GLUE. Caution Fill the holes 1/4 to 1/2 full with GLUE. Inspect the parts thoroughly before assembling. Disassembly of glued parts is extremely diffi cult. Rounded edge Rounded edge Page 18 414443 www.sauder.com/services...
  • Page 19 Use four BLACK 1-9/16" FLAT HEAD SCREWS (30S). NOTE: Be sure the DRAWER BOTTOM (D721) inserts into the groove in the å DRAWER BACK (D75) Repeat this step for the other drawer using the LEFT DRAWER FRONT (P). å www.sauder.com/services 414443 Page 19...
  • Page 20 Screw head - turn CAM to line up holes in SLIDES with holes in DRAWER SIDES. Roller end SILVER 5/8" MACHINE SCREW (4 used for the PULLS) GOLD 5/16" FLAT HEAD SCREW (8 used in this step) Page 20 414443 www.sauder.com/services...
  • Page 21 Push a CAM COVER (12P) onto each visible HIDDEN CAM å in the SIDE SKIRTS (N). 50 lbs. 10 lbs. 10 lbs. 25 lbs. (2 used) To cover HIDDEN CAMS www.sauder.com/services 414443 Page 21...
  • Page 22 #3. The higher the screw in the oblong hole, the higher your drawer front will be. The lower the screw, the lower the drawer front. Page 22 414443 www.sauder.com/services...
  • Page 23 Modèle 414443 Table de salon Utilisez les instructions d’ a ssemblage en français avec les NOUS SOMMES LA POUR VOUS AIDER! schémas étape par étape du manuel d’instruction en anglais. Nous faisons de notre mieux pour nous assurer que votre meuble Chaque étape en français correspond à...
  • Page 24 (H). Serrer cinq EXCENTRIQUES ESCAMOTABLES. REMARQUE : S'assurer de bien insérer la CHEVILLE EN BOIS (15F) située sur le PIED ARRIÈRE GAUCHE (J) dans le trou de la PLINTHE ARRIÈRE (M). Nettoyer l'excès de COLLE. Page 24 414443 www.sauder.com/services...
  • Page 25 3 Fixer l'ARRIÈRE DE TIROIR (D75) aux CÔTÉS DE TIROIR (D83 et D84). Utiliser quatre VIS TÊTE PLATE 40 mm NOIRES (30S). Répéter cette étape pour l'autre tiroir en utilisant le DEVANT DE TIROIR GAUCHE (P). www.sauder.com/services 414443 Page 25...
  • Page 26 Modelo 414443 Mesa de sofá Use estas instrucciones de ensamblaje en español junto con las ESTAMOS AQUI PARA AYUDAR! fi guras paso-a-paso provistas en el folleto inglés. Cada paso Tratamos de asegurar que su mueble llega en condición excelente. en español corresponde al mismo paso en inglés. Se destacan Nuestros representantes de Servicio al Cliente son amables y las fi...
  • Page 27 FALDÓN LATERAL (N) al ESTANTE (E), al DORSO (G) y a la RIOSTRA (H). Apriete cinco EXCÉNTRICOS ESCONDIDOS. NOTA: Asegúrese de insertar el PASADOR DE MADERA (15F) de la PATA POSTERIOR IZQUIERDA (J) dentro del agujero del FALDÓN POSTERIOR (M). Quite el exceso de PEGAMENTO. www.sauder.com/services 414443 Page 27...
  • Page 28 3 Fije el DORSO DE CAJÓN (D75) a los LADOS DE CAJÓN (D83 y D84). Utilice cuatro TORNILLOS NEGROS DE CABEZA PERDIDA de 40 mm (30S). Repita este paso para el otro cajón utilizando la CARA IZQUIERDA DE CAJÓN (P). Page 28 414443 www.sauder.com/services...
  • Page 29 à Les téléviseurs peuvent être particulièrement un téléviseur. cet eff et. lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. www.sauder.com/services 414443 Page 29...
  • Page 30 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y propensa a volcarse hacia adelante. Page 30 414443 www.sauder.com/services...
  • Page 31 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 32 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
